81
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
< DIODE >
D1001 8-719-911-19 DIODE 1SS133T-72
D1002 8-719-911-19 DIODE 1SS133T-72
< IC >
IC1001 8-749-016-76 IC RPI-321
IC1002 8-749-016-76 IC RPI-321
< TRANSISTOR >
Q1001 8-729-029-56 TRANSISTOR DTA144ESA-TP
< RESISTOR >
R907 1-247-879-11 CARBON 100K 5% 1/4W
R1001 1-249-409-11 CARBON 220 5% 1/4W F
R1002 1-249-409-11 CARBON 220 5% 1/4W F
R1003 1-249-414-11 CARBON 560 5% 1/4W F
R1004 1-247-834-11 CARBON 1.3K 5% 1/4W
R1005 1-247-818-11 CARBON 300 5% 1/4W
R1006 1-247-864-11 CARBON 24K 5% 1/4W
R1007 1-247-780-00 CARBON 7.5 5% 1/4W
R1008 1-249-417-11 CARBON 1K 5% 1/4W F
< VARIABLE RESISTOR >
RV1001 1-241-785-11 RES, ADJ, CARBON 10K
RV1002 1-241-785-11 RES, ADJ, CARBON 10K
< SWITCH >
S1001 1-570-953-11 SWITCH, PUSH (1 KEY) (DECK A PLAY)
S1002 1-570-953-11 SWITCH, PUSH (1 KEY) (DECK B PLAY)
S1003 1-771-333-11 SWITCH, LEAF (DECK A HALF)
S1004 1-771-536-11 SWITCH, LEAF (DECK A 120/70)
S1005 1-771-536-11 SWITCH, LEAF (DECK A REC)
S1006 1-771-333-11 SWITCH, LEAF (DECK B HALF)
S1008 1-771-536-11 SWITCH, LEAF (DECK B 120/70)
S1009 1-771-536-11 SWITCH, LEAF (DECK B REC)
**************************************************************
1-671-508-11 LOAD MOTOR BOARD
******************
< CAPACITOR >
C703 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C704 1-126-964-11 ELECT 10uF 20.00% 50V
C712 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
< CONNECTOR >
CN713 1-506-469-11 PIN, CONNECTOR 4P
< DIODE >
D702 8-719-109-85 DIODE MTZJ-T-72-5.1B
< IC >
IC702 8-759-633-65 IC M54641L
< RESISTOR >
R703 1-249-411-11 CARBON 330 5% 1/4W
R704 1-249-401-11 CARBON 47 5% 1/4W F
**************************************************************
A-4473-285-A MAIN BOARD, COMPLETE (EA)
*********************
A-4473-003-A MAIN BOARD, COMPLETE (SP,MY,HK)
*********************
A-4473-280-A MAIN BOARD, COMPLETE (TH)
*********************
4-875-327-31 HEAT SINK
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C103 1-126-960-11 ELECT 1uF 20.00% 50V
C107 1-136-157-00 MYLAR 0.022uF 5.00% 50V
C108 1-136-157-00 MYLAR 0.022uF 5.00% 50V
C109 1-163-019-00 CERAMIC CHIP 0.0068uF 10% 50V
C110 1-163-019-00 CERAMIC CHIP 0.0068uF 10% 50V
C111 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C112 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C113 1-126-964-11 ELECT 10uF 20.00% 50V
C114 1-136-495-11 MYLAR 0.068uF 5.00% 50V
C115 1-130-481-00 MYLAR 0.0068uF 5% 50V
C116 1-130-481-00 MYLAR 0.0068uF 5% 50V
C117 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C118 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C119 1-136-159-00 MYLAR 0.033uF 5.00% 50V
C120 1-126-964-11 ELECT 10uF 20.00% 50V
C121 1-126-964-11 ELECT 10uF 20.00% 50V
C122 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C123 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C124 1-126-960-11 ELECT 1uF 20.00% 50V
C125 1-104-665-11 ELECT 100uF 20.00% 10V
C126 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C127 1-104-664-11 ELECT 47uF 20.00% 16V
C128 1-104-664-11 ELECT 47uF 20.00% 16V
C129 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C132 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C136 1-126-964-11 ELECT 10uF 20.00% 50V
C137 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C138 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C153 1-126-960-11 ELECT 1uF 20.00% 50V
C155 1-126-964-11 ELECT 10uF 20.00% 50V
C157 1-136-157-00 MYLAR 0.022uF 5.00% 50V
C158 1-136-157-00 MYLAR 0.022uF 5.00% 50V
C159 1-163-019-00 CERAMIC CHIP 0.0068uF 10% 50V
C160 1-163-019-00 CERAMIC CHIP 0.0068uF 10% 50V
C161 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C162 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C163 1-126-964-11 ELECT 10uF 20.00% 50V
C164 1-136-495-11 MYLAR 0.068uF 5.00% 50V
C165 1-130-481-00 MYLAR 0.0068uF 5% 50V
C166 1-130-481-00 MYLAR 0.0068uF 5% 50V
C167 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C168 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C169 1-136-159-00 MYLAR 0.033uF 5.00% 50V
C170 1-126-964-11 ELECT 10uF 20.00% 50V
C171 1-126-964-11 ELECT 10uF 20.00% 50V
C172 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C173 1-136-165-00 MYLAR 0.1uF 5.00% 50V
MAINLEAF SW LOAD MOTOR
