Sony HDC-P1 - Initial Settings for Adjustment

3-6 (E)
HDC-P1
3-1-7. Initial Settings
n
This section describes the adjustment procedures using MSU-900.
When MSU-950 is used
. Power supply and signal switching block
ALL button → OFF (dark)
CAM PW button → ON (lit)
VF PW button → ON (lit)
TEST 1 button → OFF (dark)
TEST 2 button → OFF (dark)
BARS button → OFF (dark)
CLOSE button → ON (lit)
. Camera/CCU circuit ON/OFF block
Knee Off
*
→ OFF (lit in reverse)
Detail Off
*
→ OFF (lit in reverse)
Level Dep Off
*
→ OFF (lit in reverse)
Matrix Off
*
→ OFF (lit in reverse)
AUTO KNEE button → OFF (dark)
SKIN DETAIL button → OFF (dark)
. Others
Gamma Off
*
→ ON (lit normally)
Master Gain
*
→ 0 (0 dB)
ND (1/2/3/4)
*
→ 1 (CLEAR)
CC (A/B/C/D)
*
→ B (3200 K)
ECS/Shutter
*
→ OFF (lit normally)
*: Push the FUNCTION button, then select on the function menu screen.
When adjusting using the Setup menu
. PAINT menu
Page Setting item Initial setting
SW STATUS FLARE ON
GAMMA ON
BLK GAM OFF
KNEE OFF
WHT CLIP OFF
DETAIL ON
LVL DEP ON
SKIN DTL OFF
MATRIX OFF
VIDEO LEVEL TEST OFF
. Filter position
ND fi lter → 1 (CLEAR)
CC fi lter → B (3200 K)
MSU control panel
When MSU-900 is used
. Power supply and signal switching block
ALL button → OFF (dark)
CAM PW button → ON (lit)
VF PW button → ON (lit)
TEST 1 button → OFF (dark)
TEST 2 button → OFF (dark)
BARS button → OFF (dark)
CLOSE button → ON (lit)
. Camera/CCU circuit ON/OFF block
KNEE OFF button → OFF (lit)
DETAIL OFF button → OFF (lit)
LVL DEP OFF button → OFF (lit)
MATRIX OFF button → OFF (lit)
AUTO KNEE button → OFF (dark)
SKIN DETAIL button → OFF (dark)
. Others
GAMMA OFF button → ON (dark)
MASTER GAIN → 0 (0 dB)
FILTER button (ND) → 1 (CLEAR)
FILTER button (CC) → B (3200 K)
ECS/SHUTTER ON button → OFF (dark)
