This unit is equipped with various fi le systems for managing data.
In this section, the menu operations are described as follows.
Example: When executing WRITE (CAM → MS) on the OPERATOR FILE page of the OPERATION
menu.
As for the details on the setup menu, refer to Section 5.
4-1. File Structure
The following six types of fi les are available. As for the items to be stored in each fi le, refer to “Section
4-8 File Items”.
1. Operator File
Stores the items displayed on the viewfi nder and switch settings for camera operator. This fi le can be
stored in a Memory Stick Duo, yet video data (paint data) cannot be stored.
2. Preset Operator File
Stores the standard settings of operator fi le.
This fi le can be stored in the camera, yet video data (paint data) cannot be stored.
3. Scene File
Stores the temporary video setting data according to the scene. This fi le can be stored in the camera
and a Memory Stick Duo.
4. Reference File
Stores the custom paint data adjusted by the video engineer. This fi le can be stored in the camera and
a Memory Stick Duo.
5. Lens File
Used for compensation of the deviation which is generated by switching the lens extender from OFF
to ON and for compensation of the difference in the characteristics between lenses. This fi le is stored
in the camera.
6. OHB File
Used for adjustment of the CCD block maintenance. This fi le can be stored in the camera.
When STANDARD
is executed
Factory-set value 0
Fig. 4-1. Structure of Paint Related Files
Output to
hardware
*1
Scene File
Refer to “Section 4-8 File Items”.
Lens File
When lens extender setting is OFF:
Flare R/G/B and V Modulation Shading R/G/B/Master can be stored.
Auto Iris Gain can also be stored.
When lens extender setting is ON:
White R/B, Flare R/G/B, and V Modulation Shading R/G/B/Master can be stored.
Auto Iris Gain can also be stored.
Reference File
Refer to “Section 4-8. File Items”.
OHB File
. Black shading:
R/G/B for H SAW, H PARA, V SAW, V PARA can be stored.
. White shading:
R/G/B for H SAW, H PARA, V SAW, V PARA can be stored.
. ND offset can be stored.
. OHB matrix can be stored.
(*1): The additional data of each file is sent to each circuit in the unit.
