3-9. TEST SAW Level Adjustment
When the CCD block assembly (RP) has been replaced, the TEST SAW level (700 mV) may deviate by
?30 mV. Adjust the level using the following procedure.
Equipment
HDTV serial digital waveform monitor: Leader Electronics LV5150DA
Leader Electronics LV5152DA (multi format)
or equivalent
Preparation
. MSU-900 settings
GAMMA OFF button → ON (dark)
MASTER GAIN → 0 dB
DETAIL OFF button → ON (dark)
KNEE OFF button → OFF (lit)
MASTER BLACK → 0
MATRIX OFF button → OFF (lit)
. Menu settings
1. MENU: FILE
PAGE: FILE CLEAR
ITEM: REFERENCE (ALL) 10 SEC CLEAR → ON
2. MENU: PAINT
PAGE: VIDEO LEVE
ITEM: WHITE [R], [G], [B]
Set the cursor at WHITE [R] and press the menu
control knob for at least 10 seconds.
[REF CLEARED] appears after [PRESET DATA] is
displayed.
3. Make settings for WHITE [G] and WHITE [B] in the
same way.
4. Set ITEM in step 1 (REFERENCE (ALL) 10 SEC
CLEAR) to OFF.
<FILE CLEAR> F06 TOP
PRESET OPERATOR
REFERENCE(ALL)
10 SEC CLEAR:
m
ON
OHB WHITE SHADE(ALL)
OHB BLACK SHADE
OHB ND OFFSET
OHB MATRIX
M.S. FORMAT
<VIDEO LEVEL> P02 TOP
PRESET DATA
[R] [G] [B] [M]
WHITE :? 0 0 0
BLACK : 0 0 0 0
FLARE : 0 0 0
GAMMA : 0 0 0 0
V MOD : 0 0 0 0
FLARE : ON
V MOD : ON D.SHAD: --
TEST : OFF
<VIDEO LEVEL> P02 TOP
REF CLEARED
[R] [G] [B] [M]
WHITE :? 0 0 0
BLACK : 0 0 0 0
FLARE : 0 0 0
GAMMA : 0 0 0 0
V MOD : 0 0 0 0
FLARE : ON
V MOD : ON D.SHAD: --
TEST : OFF
