HDC-P1
Manual Structure
Purpose of this manual
This manual is the maintenance manual for HD MULTI PURPOSE CAMERA
HDC-P1.
This manual describes the information items that premise the service based on the
components parts such as replacement of main parts, electrical alignment, schematic
diagrams, board layouts and detailed parts list assuming use of system and service
engineers.
Related manuals
Besides this maintenance manual the following manual is available for this unit.
. HDC-P1 Operation Manual (Supplied with HDC-P1)
This manual is necessary for application and operation of HDC-P1.
Part number: 4-170-164-0X (Japanese)
Part number: 4-170-168-0X (English)
. “Semiconductor Pin Assignments” CD-ROM (Available on request)
This “Semiconductor Pin Assignments” CD-ROM allows you to search for semi-
conductors used in Broadcast and Professional equipment.
This manual contains a complete list of semiconductors and their ID Nos., and thus
should be used together with the CD-ROM.
Part number: 9-968-546-06
Trademarks
Trademarks and registered trademarks used in this manual are follows.
. FRAM is a registered trademark of Ramtron International Corporation.
