42
3. Remove the set screw, and then remove the filter knob.
4. Remove the four bolts (M3 x 8) and the four spring washers, and then remove the CMOS block assembly.
5. Remove the filter sheet.
CMOS block assembly
Filter sheet
Spring washers
Spring washers
Set screw
Filter knob
M3 x 8
(tightening torque: 1.1 ± 0.05 N·m)
M3 x 8
(tightening torque: 1.1 ± 0.05 N·m)
