Section 5
Electrical Alignment
When any board of this unit is repaired or replaced, adjust this unit for electrical alignment as this section.
• Perform the “5-4. Video System Level Adjustment” according to the system that the customer uses.
• Master setup unit MSU-1000/1500/3000/3500 is used for electrical alignment of the unit.
Without using master setup unit (here after MSU), the electrical alignment also can be made using remote control unit
(RCP-1000/1500/3500) or setting menu of the camera.
Refer to “5-1-7. Setup Menu Correspondence List” for detail of setup menu.
5-1. Preparations
Turn on power switch of this unit before starting adjustments, and warm up the unit for about 10 minutes.
5-1-1. Required Equipment and Tool
Use calibrated equipment and tools.
Equipment Required
Name Equipment
HD waveform monitor Leader Electronics LV5152DA (multi waveform monitor) or equivalent
HD color monitor Sony BVM-E171 or equivalent
Master setup unit Sony MSU-1000/1500
Lens Canon HJ18 or equivalent
Frequency counter Advantest TR5821AK or equivalent
Tool
Name Sony Part No. Remarks
Grayscale chart (16:9 reflective type) —
Commercially available
Since time degradation is appeared, replace for every two years.
(The exchange time, change by the safekeeping situation.)
Grayscale chart (16:9 transparent type) J-6394-080-A Use when the grayscale chart (16:9 reflective type) is not available.
Pattern box PTB-500 J-6029-140-B
Chart adaptor J-7120-950-A
Adaptor that installs ITE test chart (16:9) 310×200 in PTB-500 (pattern
box)
ITE standard test chart J-7120-970-A ITE grayscale chart (γ=0.45) (16:9)
