41
<VF MARKER>
03 (U06)
MARKER ON
, OFF Sets the display of all markers on/off.
WHITE
, BLACK, DOT
LEVEL MIN, 1 to 10, 4
CENTER ON, OFF
1, 2, 3, 4 1: Full cross
2: Full cross with a hole
3: Center
4: Center with a hole
SAFETY ZONE ON, OFF
80.0, 90.0, 92.5, 95.0%
EFFECT ON, OFF
ASPECT ON, OFF
16:9, 15:9, 14:9, 13:9, 4:3 (4.3): If VF SCAN is set to 4:3 when HDLA is attached
(cannot be changed)
MASK ON, OFF
(ON): If VF SCAN is set to 4:3 when HDLA is attached
(cannot be changed)
0 to 15, 12
Sets the darken level outside the aspect area.
SAFETY ON, OFF
For the safety marker in Aspect mode.
80.0, 90.0
, 92.5, 95.0%
<VF DETAIL>
04 (U02)
VF DETAIL ON
, OFF, (ON), (OFF) Settings in ( ): When HDLA is attached (cannot be
changed)
0 to 100%, (0 to 100%), 25%
CRISP –99 to +99, 0
FREQUENCY 9M, 14M, 18M
FLICKER ON, OFF
AREA 10 to 100%, 100%
ZOOM LINK ON, OFF
0 to 100%, 50%
COLOR DETAIL ON, OFF
YELLOW, RED, BLUE
PEAK COLOR ON, OFF
CHROMA LEVEL 100%, 50%, 25%, 0%
RETURN DISABLE ON, OFF
Selects whether to set VF DETAIL to OFF for RETURN
display.
<DYNAMIC FOCUS>
05
DYNAMIC FOCUS OFF
, ON, (OFF) (OFF): Displayed for formats other than 4K/HDR
format.
FREQUENCY EXTRA-LOW
, LOW, MID, HIGH,
(AUTO)
Sets the bandwidth of the 4K resolution high-
frequency signal to detect.
(AUTO): Displayed when ZOOM LINK is set to ON.
ZOOM LINK ON, OFF
MODE1, MODE2, MODE3,
MODE4
Sets characteristics according to the zoom position.
0 to 100%, 50%
(5% increments)
Sets the level at the WIDE position mark.
CRISP 0 to 99, 6
Adjust to eliminate minute components of the
detected signal.
LEVEL LOW
, MIDDLE, HIGH,
VERY-HIGH
Sets the brightness level of the marking signal.
PEAK COLOR OFF, RED, BLUE, GREEN,
BROWN, PURPLE, YELLOW
THRESHOLD 0 to 99, 50 Sets the threshold level for adding color specified
using PEAK COLOR.
COLOR LEVEL 0 to 99, 19
Sets the saturation of the color of the PEAK COLOR
indicator.
OPERATION
Page name
Page No.
Item Settings Description
