HDC3500
Optional accessories/related equipment
Large Viewfinder
Adaptor
HDLA1507
Microphone Holder CAC-12
Return Video Selector CAC-6
Tripod Attachment VCT-14
Low-repulsion
Shoulder Pad
A-8286-346-A
Related equipment
HDCU5000/5500 Camera Control Unit
RCP-3000/1000 series Remote Control Panel
CNA-1 Camera Control Network Adaptor
General
Power requirements 240 V AC, 1.4 A (max.)
12 V DC, 9.5 A (max.)
240 V DC, 1.05 A (max.)
Operating
temperature
–20 °C to +45 °C (–4 °F to +113 °F)
Storage temperature –20 °C to +60 °C (–4 °F to +140 °F)
Mass Approx. 4.9 kg (10 lb 13 oz) (HDC3500 as
shipped)
Approx. 5.1kg (11lb 4oz)
(when HKC-TR37 is installed)
Approx. 4.9 kg (10 lb 13 oz)
(when HKC-FB30 is installed)
Approx. 5.0 kg (11 lb 0.4 oz)
(when HKC-FB50 is installed)
Dimensions See
page 100 .
Imager
Imager 2/3 inch CMOS sensor with global shutter
Method 3-chip, RGB
Electrical characteristics
Sensitivity F10.0 with 1080/59.94P
F11.0 with 1080/50P
(Progressive output option installed)
(at 2000 lx with 89.9% reflectance)
Noise level –62 dB
Horizontal resolution 2000 TV lines (at center of screen, 4K
output option installed)
5% or higher modulation
Geometric distortion Negligible (not including lens distortion)
Optical system specifications
Spectral system F1.4 prism
Built-in filters ND filters
1: CLEAR
2: 1/4ND
3: 1/8ND
4: 1/16ND
5: 1/64ND
Color temperature conversion filters
A: cross filter
B: 3200K(clear)
C: 4300K
D: 6300K
Input/output connectors
CCU Optical/electrical multi-connector (1)
LENS 12-pin (1)
VF 20-pin (1)
MIC 1 IN XLR 3-pin, female (1)
AUDIO IN CH1, CH2 XLR 3-pin, female (1 each)
AUDIO switch for MIC: –60 dBu (can be
selected up to –20 dBu in the menu),
balanced
AUDIO switch for LINE: 0 dBu, balanced
INTERCOM 1,
INTERCOM 2
XLR 5-pin, female (1 each)
EARPHONE 4-pole mini jack (1)
(2-polo mono, 3-pole stereo, 4-pole CTIA
standard, 4-pole OMTP standard)
DC IN XLR 4-pin (1), DC 10.5 V to 17 V
DC OUT 4-pin (1), DC 10.5 V to 17 V, max. 0.5 A
(This may be limited by the imposed load
or inputs.)
2-pin (1), DC 10.5 V to 17 V
Max. 2.5 A
(This may be limited by the imposed load
or inputs.)
SDI 1, SDI 2 BNC-type (1-each)
SDI MONI BNC-type (1)
TEST OUT BNC-type (1)
PROMPTER/GENLOCK BNC-type (1)
PROMPTER 1 Vp-p, 75 Ω
GENLOCK HD: SMPTE ST274, tri-level
sync, 0.6 Vp-p, 75 Ω
SD: Black burst
(NTSC: 0.286 Vp-p, 75 Ω /
PAL: 0.3 Vp-p, 75
Ω )
PROMPTER2 BNC-type (1), 1 Vp-p, 75 Ω
RET CTRL 6-pin (1)
REMOTE 8-pin (1)
TRACKER 12-pin (1)
CRANE 12-pin (1)
USB USB 2.0 Type A 4-pin (1) (for connecting
USB drive)
NETWORK TRUNK RJ-45 type 8-pin (1)
Supplied accessories
Before Using This Unit (1)
Operating Instructions (CD-ROM) (1)
Cable clamp belt (1 set)
Screws (+B3×8) (2)
Attached label (1)
Optional accessories
Triax Transmission
Adaptor
HKC-TR37
Side Panel
Attachment Kit
HKC-CN50
UHB Fiber
Transmission Adaptor
HKC-FB50
Fiber Transmission
Adaptor
HKC-FB30
