DIAGNOSIS Menu
This menu is only for viewing and camera settings cannot
be made using this menu.
However, some items set the conditions for viewing.
DIAGNOSIS
Page title
Page No.
Item Indication Description
<OPTICAL LEVEL>
D01
CCU t CAM GREEN, YELLOW, RED, NG, NO SIGNAL Not displayed when the HKC-TR37 is
installed.
NO SIGNAL: When CCU is not connected
CAM t CCU GREEN, YELLOW, RED, NG, NO SIGNAL
REFLECTION OK, NG, -- Not displayed when the HKC-TR37 is
installed.
--: When CCU is not connected
CABLE LENGTH x.x km Displays the camera cable length.
(Displayed only when a CCU is connected.)
Not displayed when the HKC-TR37 is
installed.
<BOARD STATUS>
D02
OHB OK, NG
DPR OK, NG
SY OK, NG
PS OK, NG
TX OK, NG Not displayed when the HKC-TR37 is
installed.
CD OK, NG Displayed only when the HKC-TR37 is
installed.
HOURS METER xxxx H Displays the total working time.
<ROM VERSION>
D03 (U15)
CAMERA APP Vx.xx
OS Vx.xx
UPDATER Vx.xx
PANEL Vx.xx Displayed only when HDLA is attached.
SY Vx.xx
DPR Vx.xx
PS Vx.xx
TX Vx.xx Not displayed when the HKC-TR37 is
installed.
CD1 OK, NG Displayed only when the HKC-TR37 is
installed.
CD2 OK, NG
TR OK, NG
<SERIAL NO.>
D04
MODEL xxxxxxx Displays the model name.
NO. xxxxxxx Displays the serial number.
EFFECTIVE FUNCTION Displayed if any option is installed.
<POWER SUPPLY
STATUS>
D05
Note
This display has a
margin of error for
the display of the
electric supply state
of a camera. Use only
as a guide.
CAM LENGTH x.x km Displays the cable length that a CCU
measured. (Displayed only when a CCU is
connected.)
Not displayed when the HKC-TR37 is
installed.
CABLE MARGIN x.x m Displays the possible cable length
extension. (Displayed only when a CCU is
connected.)
Not displayed when the HKC-TR37 is
installed.
CAM INPUT VOLTAGE 0% to 100% Displays the ratio of the input voltage on
the camera to the output voltage on the
CCU.
CAM CONSUMPTION 0% to 100% Displays camera power consumption.
