Specifications
HDC5500
Optional accessories/related equipment
General
Power requirements 240 V AC, 1.4 A (max.)
12 V DC, 9.5 A (max.)
240 V DC, 1.05 A (max.)
Operating temperature –20 °C to +45 °C (–4 °F to +113 °F)
Storage temperature –20 °C to +60 °C (–4 °F to +140 °F)
Mass Approx. 5.0 kg (11 lb 0.4 oz) (Unit only)
External dimensions See
page 100
.
Imaging element
Imaging element 2/3 inch CMOS sensor with global
shutter
Form 3-chip, RGB
Electrical characteristics
Sensitivity F10.0 with 1080/59.94P
F11.0 with 1080/50P
(at 2000 lx with 89.9% reflectance)
Noise level –62 dB
Horizontal resolution 2000 TV lines at center of screen
5% or higher modulation
Geometric distortion Negligible (not including lens
distortion)
Optical system specifications
Spectral system F1.4 prism
Built-in filters ND filters
1: CLEAR
2: 1/4ND
3: 1/8ND
4: 1/16ND
5: 1/64ND
Color temperature conversion filters
A: Cross filter
B: 3200K (clear)
C: 4300K
D: 6300K
Input/output connectors
CCU Optical/electrical multi connector (1)
LENS 12-pin (1)
VF 20-pin (1)
MIC 1 IN XLR 3-pin, female (1)
AUDIO IN CH1, CH2 XLR 3-pin, female (1 each)
When AUDIO switch is set to MIC:
–60 dBu (can be selected up to
–20 dBu by menu operation),
balanced
When AUDIO switch is set to LINE:
0 dBu, balanced
INTERCOM 1, INTERCOM
2
XLR 5-pin, female (1 each)
EARPHONE 4-pole mini jack (1)
(2-polo mono, 3-pole stereo, 4-pole
CTIA standard, 4-pole OMTP standard)
DC IN XLR 4-pin (1), 10.5 V to 17 V DC
DC OUT 4-pin (1), 10.5 V to 17 V DC, max. 0.5 A
(This may be limited by the imposed
load or input conditions.)
2-pin (1), 10.5 V to 17 V DC, max. 2.5 A
(This may be limited by the imposed
load or input conditions.)
SDI 1, SDI 2, SDI 3 BNC type (1 each)
SDI MONI BNC type (1)
TEST OUT BNC type (1)
PROMPTER/GENLOCK BNC type (1)
PROMPTER 1 Vp-p, 75 Ω
GENLOCK HD: SMPTE ST274,
tri-level sync, 0.6 Vp-p,
75 Ω
SD: Black burst (NTSC:
0.286 Vp-p, 75 Ω/
PAL: 0.3 Vp-p, 75 Ω)
RET CTRL 6-pin (1)
REMOTE 8-pin (1)
TRACKER 12-pin (1)
CRANE 12-pin (1)
USB USB 2.0 Type A 4-pin (1) (for connecting
USB drive)
NETWORK TRUNK RJ-45 type 8-pin (1)
Supplied accessories
Before Using This Unit (1)
Operating Instructions (CD-ROM) (1)
Cable clamp belt (1 set)
Screws (+B3×8) (2)
Attached label (1)
Optional accessories
Triax Transmission
Adaptor
HKC-TR37
Side Panel Attachment
Kit
HKC-CN50
UHB Fiber Transmission
Adaptor
HKC-FB50
Fiber Transmission
Adaptor
HKC-FB30
Camera Operating
Software
HZC-DFR50/DFR50M/DFR50W
HZC-HFR50/HFR50M/HFR50W/
HFR50P
HZC-PRV50/PRV50M/PRV50W
HZC-PSF50/PSF50M/PSF50W
HZC-UHD50/UHD50M/UHD50W/
UHD50P
HZC-UG50/UG50M/UG50W
Wireless Transmission
Adaptor
HKC-WL50
HD Electronic
Viewfinder
HDVF-EL20 (0.7-type, color)
HDVF-EL30 (0.7-type, color)
HDVF-EL75 (7.4-type, color)
HDVF-L750 (7-type, color)
HDVF-L770 (7-type, color)
Large Lens Adaptor HDLA1500/1505
