<When HZC-DFR50/DFR50M/DFR50W is installed>
*1
Can be selected only when NETWORK TRUNK > DATA RATE (setting on the CCU) is set to 100Mbps.
*2
Can be selected only when a CCU is connected.
*3
Can be selected only in standalone operation.
SYSTEM FORMAT HDR/
SDR
OUTPUT FORMAT
SDI-1 SDI-2
RESOLUTION FREQUENCY OETF Settings Output formats Settings Output formats
1920×1080 59.94P(2×) S-Log3
HLG
OFF
HD/12G/HDR/HFR
HD/3G-A/HDR/HFR
HD/3G-B/HDR/HFR
HD/3G-A/SDR
HD/3G-B/SDR
HD/1.5G/SDR
UHD PROMPTER
–
1920×1080/59.94P/Link A-B
1920×1080/59.94P/Link A
1920×1080/59.94P/Link A
1920×1080/59.94P
1920×1080/59.94P
1920×1080/59.94i
–
OFF
HD/12G/HDR/HFR
HD/3G-A/HDR/HFR
HD/3G-B/HDR/HFR
HD/3G-A/SDR
HD/3G-B/SDR
HD/1.5G/SDR
UHD TRUNK(12G) IN
*1 *2
UHD TRUNK(6G) IN
*1 *2
UHD TRUNK(3G) IN
*1 *2
HD/UHD TRUNK(1.5G) IN
*2
HD RETURN IN
*3
–
1920×1080/59.94P/Link A-B
1920×1080/59.94P/Link B
1920×1080/59.94P/Link B
1920×1080/59.94P
1920×1080/59.94P
1920×1080/59.94i
–
–
–
–
–
SDR OFF
HD/12G/SDR/HFR
HD/3G-A/SDR/HFR
HD/3G-B/SDR/HFR
HD/3G-B/SDR/HFR(i)
HD/3G-A/SDR
HD/3G-B/SDR
HD/1.5G/SDR
UHD PROMPTER
–
1920×1080/59.94P/Link A-B
1920×1080/59.94P/Link A
1920×1080/59.94P/Link A
1920×1080/59.94i/Link A-B
1920×1080/59.94P
1920×1080/59.94P
1920×1080/59.94i
–
OFF
HD/12G/SDR/HFR
HD/3G-A/SDR/HFR
HD/3G-B/SDR/HFR
HD/3G-B/SDR/HFR(i)
HD/3G-A/SDR
HD/3G-B/SDR
HD/1.5G/SDR
UHD TRUNK(12G) IN
*1 *2
UHD TRUNK(6G) IN
*1 *2
UHD TRUNK(3G) IN
*1 *2
HD/UHD TRUNK(1.5G) IN
*2
HD RETURN IN
*3
–
1920×1080/59.94P/Link A-B
1920×1080/59.94P/Link B
1920×1080/59.94P/Link B
1920×1080/59.94i/Link A-B
1920×1080/59.94P
1920×1080/59.94P
1920×1080/59.94i
–
–
–
–
–
