78
<When HZC-PSF50/PSF50M/PSF50W is installed>
*1
Can be selected only when NETWORK TRUNK > DATA RATE (setting on the CCU) is set to 100Mbps.
*2
Can be selected only when a CCU is connected.
*3
Can be selected only in standalone operation.
SYSTEM FORMAT HDR/
SDR
OUTPUT FORMAT
SDI-1 SDI-2
RESOLUTION FREQUENCY OETF Settings Output formats Settings Output formats
1920×1080 25PsF S-Log3
HLG
OFF
HD/1.5G/HDR
HD/1.5G/SDR
UHD PROMPTER
–
1920×1080/25PsF
1920×1080/25PsF
–
OFF
HD/1.5G/HDR
HD/1.5G/SDR
UHD TRUNK(12G) IN
*1 *2
UHD TRUNK(6G) IN
*1 *2
UHD TRUNK(3G) IN
*1 *2
HD/UHD TRUNK(1.5G) IN
*2
HD RETURN IN
*3
–
1920×1080/25PsF
1920×1080/25PsF
–
–
–
–
–
SDR OFF
HD/1.5G/SDR
UHD PROMPTER
–
1920×1080/25PsF
–
OFF
HD/1.5G/SDR
UHD TRUNK(12G) IN
*1 *2
UHD TRUNK(6G) IN
*1 *2
UHD TRUNK(3G) IN
*1 *2
HD/UHD TRUNK(1.5G) IN
*2
HD RETURN IN
*3
–
1920×1080/25PsF
–
–
–
–
–
24PsF S-Log3
HLG
OFF
HD/1.5G/HDR
HD/1.5G/SDR
UHD PROMPTER
–
1920×1080/24PsF
1920×1080/24PsF
–
OFF
HD/1.5G/HDR
HD/1.5G/SDR
UHD TRUNK(12G) IN
*1 *2
UHD TRUNK(6G) IN
*1 *2
UHD TRUNK(3G) IN
*1 *2
HD/UHD TRUNK(1.5G) IN
*2
HD RETURN IN
*3
–
1920×1080/24PsF
1920×1080/24PsF
–
–
–
–
–
SDR OFF
HD/1.5G/SDR
UHD PROMPTER
–
1920×1080/24PsF
–
OFF
HD/1.5G/SDR
UHD TRUNK(12G) IN
*1 *2
UHD TRUNK(6G) IN
*1 *2
UHD TRUNK(3G) IN
*1 *2
HD/UHD TRUNK(1.5G) IN
*2
HD RETURN IN
*3
–
1920×1080/24PsF
–
–
–
–
–
25PsF(444)
(HZC-UG50 is
required)
SDR
(fixed)
OFF
HD/3G-B/SDR
UHD PROMPTER
–
1920×1080/25PsF(444)
–
OFF
HD/3G-B/SDR
UHD TRUNK(12G) IN
*1 *2
UHD TRUNK(6G) IN
*1 *2
UHD TRUNK(3G) IN
*1 *2
HD/UHD TRUNK(1.5G) IN
*2
HD RETURN IN
*3
–
1920×1080/25PsF(444)
–
–
–
–
–
24PsF(444)
(HZC-UG50 is
required)
SDR
(fixed)
OFF
HD/3G-B/SDR
UHD PROMPTER
–
1920×1080/24PsF(444)
–
OFF
HD/3G-B/SDR
UHD TRUNK(12G) IN
*1 *2
UHD TRUNK(6G) IN
*1 *2
UHD TRUNK(3G) IN
*1 *2
HD/UHD TRUNK(1.5G) IN
*2
HD RETURN IN
*3
–
1920×1080/24PsF(444)
–
–
–
–
–
