(Supplementary
information)
TV Business Division
100
3.16.1 Audio D Amp IC Normal Operation Condition
3.16.1 Audio D Amp IC Normal Operation Condition
Label Name
AC Adapter PSU board Common
Voltage Voltage Frequency
1 SDI 3.3Vpp 3.3Vpp Clock signal
2 SDO 0V 0V -
3 RESETB 3.3V 3.3V -
4 LRCK 3.3Vpp 3.3Vpp 48kHz
5 SCLK 3.3Vpp 3.3Vpp 3.07MHz
6 MCLK 0V 0V -
7 DVSS 0V 0V -
8 VR_DIG 1.8V 1.8V -
9 DVDD 3.3V 3.3V -
10 AVSS 0V 0V -
11 AVCC 3.3V 3.3V -
12 GVDD 5V 5V -
13 VR_ANA 5V 5V -
14 BSTPR 14.7Vrms 11.4Vrms -
Label Name
AC Adapter PSU board Common
Voltage Voltage Frequency
15 VOUTPR 9.7Vrms 6.4Vrms ~384kHz
16 PVDDR 19.5V 12.7V
17 VOUTNR 9.7Vrms 6.4Vrms ~384kHz
18 BSTNR 14.7Vrms 11.4Vrms -
19 BSTNL 14.7Vrms 11.4Vrms -
20 VOUTNL 9.7Vrms 6.4Vrms ~384kHz
21 PVDDL 19.5V 12.7V -
22 VOUTPL 9.7Vrms 6.4Vrms ~384kHz
23 BSTPL 14.7Vrms 11.4Vrms -
24 PWDNN 3.3V 3.3V -
25 FAULTB 3.3V 3.3V -
26 A_SEL 0V 0V -
27 SDA 3.3Vpp 3.3Vpp Clock signal
28 SCL 3.3Vpp 3.3Vpp Clock signal
100
SYSSET
2018/05/0404:12:02(GMT+09:00)
