(Supplementary
information)
TV Business Division
111
3.16.2 Troubleshooting Detail Audio Problem
3.16.2.6 HDMI ARC Failure
HDMI 2
(CN4002)
HDMI 3
(CN4000)
Zoo
m
Pin 19
Pin 1
R4036
No Ref No Part No Description
1 R4036 1-218-944-81 RES, CHIP 180 (1005)
111
