40
Board
Name
Board PWB (A side) Detail
BB9 board
(A side)
(IFOUTN1)
FB1000
C1005
C1012
(IFOUTP1)
R1030
FB1001
C1006
C1013
FB1000
C1012
C1005
FB1001
C1006
C1013
R1030
SYSSET
2018/05/0404:12:02(GMT+09:00)
