28
3.5 : 5x Blinking – Panel I2C Error
START
TV set is OK now
NG Symptom:
B-Board Issue NG
TV Boots Up Normally
* O-Cell or Panel
Module replacement
depends on service
capabilities
END
Reinsert LVDS 51pin Flat
Flexible Cable (FFC) at B-Board and
Panel Side. Make sure FFC is taped
properly.
5 Times Blinking happen?
YES
No
Replace LVDS 51 pin Flat Flexible
Cable (FFC)
TV set is OK now
NG Symptom:
Incorrect FFC Insertion
5 Times Blinking happen?
YES
No
TV set is OK now
NG Symptom:
LVDS Cable NG
Replace B-Board
5 Times Blinking happen?
YES
No
Replace
O-Cell* or Panel Module*
Check voltage at +12.5V_TCON
Is 10.8 – 13.2V available?
YES
NO
TV set is OK now
NG sympton:
LD board/ G board
no +12.5V_TCON supply
SYSSET
2018/05/0404:12:02(GMT+09:00)
To Next Page
