(Supplementary
information)
TV Business Division
93
3.15 No Power DDCON/LDO
SW: +3.3V_MAIN check
Check VG signal
Q6009 #pin1
Is voltage > 3.0V?
Change Q6008
no
yes
Other Issue
START
Change Q6009
Check VB signal
Q6008 #pin2
Is voltage > 1.9V?
yes
no
93
