(Supplementary
information)
34
Board Name Board PWB (A side) Detail
BB9 board
(A side)
(3.3V)
CL1000
(1.8V)
CL1001
(12V)
CL1006
F1000
BB9 board
(A side)
Detail
CL1001
(1.8V)
CL1000
(3.3V)
F1000
CL1006
(12V)
SYSSET
2018/05/0404:12:02(GMT+09:00)
