– 9 –
KLV-19T400A,T400G,T400W
RM-GA013
SECTION 4
WIRE DRESSING
CAUTION :
1. Do not overpull the wires during dressing
--> avoid disconnection of wires.
2. Make sure wires are kept away from
sharp edges, heatsinks & other
high-temperature parts.
4-1-1. Wire Dressing overview for 19T400A
Non-CISPR model.
4-1-2. Wire Dressing overview for 19T400A
CISPR model.
4-1-3. Wire Dressing overview for
19T400W model.
4-1-4. Wire Dressing overview for
19T400G model.
Figure (a)
