– 26 –
REF NO. PART NO. DESCRIPTION REMARKREF NO. PART NO. DESCRIPTION REMARK
KLV-19T400A,T400G,T400W
RM-GA013
A-1550-359-A BT MOUNT (SERVICE) (19T400G)
A-1551-126-A BT-MOUNT (SERVICE)
(19T400W(Except GE, South Africa))
A-1556-645-A BT MOUNT (SERVICE) (19T400A)
A-1564-858-A BT MOUNT (SERVICE)
(19T400W(GE, South Africa))
A-1550-333-A HT MOUNT
* A-1551-120-A KT MOUNT (19T400W)
* A-1551-121-A J MOUNT (19T400W)
A-1551-118-A GT COMPLETE (19T400W)
A-1550-334-A GT COMPLETE (Except 19T400A(New Zealand/19T400W)
A-1556-641-A GT COMPLETE (19T400A(New Zealand))
**************
**********************************************************************
CONNECTORS
**************
* 1-910-047-12 CONNECTOR ASSY 10P
CN3001(BT)-CN1000(HT)
* 1-910-047-13 CONNECTOR ASSY 11P
CN6202(GT)-CN7000(BT)
* 1-910-047-28 CONNECTOR ASSY 3P (19T400W)
CN2800(KT)-CN3400(J)
* 1-910-047-14 CONNECTOR ASSY 4P
CN2000(BT)-SP(1)
* 1-910-047-27 CONNECTOR ASSY 5P (19T400W)
CN6201(GT)-CN2802(KT)
* 1-910-047-25 CONNECTOR ASSY 7P (19T400W)
CN2001(BT)-CN2801(KT)
1-835-721-11 HARNESS WITH CONNECTOR (LVDS)
CN3000(BT)-TCON(1)
* 1-910-047-15 SP CONNECTOR ASSY 4P
(19T400A,19T400A/H,19T400G)
* 1-910-047-56 SP CONNECTOR ASSY 4P (19T400W)
***********************************************************************
<ACCESSORIES AND PACKING MATERIALS>
*****************************************
* 4-111-953-01 CUSHION, LOWER(19)
(19T400A(South Africa,GE,Thailand),
T400A/H(E,Thailand)))
* 4-111-952-01 CUSHION, UPPER (19)
(19T400A(South Africa,GE,Thailand),19T400/H(E,Thailand)))
NOTE:
• Items marked " ∗ " are not stocked since
they are seldom required for routine
service. Some delay should be antici-
pated when ordering these items.
• All variable and adjustable resistors have
characteristic curve B, unless otherwise
noted.
• All resistors are in ohms
• F : nonflammable
CAPACITORS
• MF : µF, PF : µµF
COILS
• MMH : mH, UH : µH
REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
SECTION 8
ELECTRICAL PARTS LIST
The components identified by mark contain
confidential information. Strictly follow the
instructions whenever the components are
repaired and /or replaced.
Due to complexity of the board, performing component level field
repairs are not recommended.
Complete board replacement is required if service is necessary.
For part number information refer to the Exploded View or
Electrical Parts List section of this Service Manual.
* 3-874-041-01 CUSHION, LOWER(19)
(19T400A(E,New Zealand), ME,19T400/H(ME),19T400G)
* 3-874-040-01 CUSHION, UPPER(19)
(19T400A(E,New Zealand,ME),19T400/H(ME),19T400G)
* 4-109-579-01 CUSHION, LOWER(19W) (19T400W)
* 4-000-878-01 CUSHION, UPPER(19W) (19T400W)
* 3-874-042-01 INDIVIDUAL CARTON (19T400A,T400W/H(ME))
* 4-000-879-01 INDIVIDUAL CARTON (19T400W)
* 4-110-398-01 INDIVIDUAL CARTON
(19T400A/H(E/Thailand), 19T400G)
4-000-037-11 MANUAL, INSTRUCTION
(19T400A (ME,India)/ 19T400A/H(ME),
19T400G(ME,India), 19T400W(E,ME,India)
4-000-037-21 MANUAL, INSTRUCTION (Arabic language)
(19T00A (ME)/ 19T400A/H(ME),19T400G(ME),
19T400W(ME)
4-000-037-31 MANUAL, INSTRUCTION (PR language)
(19T00A (ME)/ 19T400A/H(ME),19T400G(ME),
19T400W(ME)
4-107-685-11 MANUAL, INSTRUCTION
(KLV-19T00A (E,GE,SA)/ A/H(E),19T400G(ME),
19T400W(ME)
4-107-685-21 MANUAL, INSTRUCTION (Thai language)
(19T00A (THAILAND)/ A/H(THAILAND))
4-107-685-31 MANUAL, INSTRUCTION (19T00A (GE)
(CT language)
4-110-401-11 MANUAL, INSTRUCTION
(19T00A (E,NEW ZEALAND)/
19T400W(THAILAND,GE)
4-110-401-21 MANUAL, INSTRUCTION (CT language)
(19T00A (E)/ T400W(GE)
4-110-401-31 MANUAL, INSTRUCTION (19T00A (E)
(PR language)
4-110-401-41 MANUAL, INSTRUCTION (Thai language)
(19T00G (THAILAND)
3-293-042-12 SUPPLEMENT (WALL MOUNT)
3-293-042-22 SUPPLEMENT (WALL MOUNT)
1-821-926-11 PLUG CONVERSION (19T00A (South Africa) ,
T400W(Thailand)
1-569-008-22 ADAPTOR, CONVERSION 2P
(19T400A,A/H,G,W (E))
1-770-019-61 ADAPTOR, CONVERSION PLUG
(Except 19T400A,A/H,G,W (E))
**************************************************************************
To Next Page
