Viewing pictures from the connected equipment
Turn on the connected equipment, then press / to display the connected equipment list.
Press F/f to select the desired input source, then press . (The highlighted item is selected if
2 seconds pass without any operation after pressing F/f.) When the input source is set to “Skip”
in the “Video Labels” under the “AV Set-up” menu (page 28), that input does not appear in the
list.
z • Press / on the TV to display the connected equipment list and select the desired input source. You can also
press F/f to select the desired input source. Then wait for 2 seconds to display the selected input source.
Jacks/
Input symbol on screen
Description
A 2, and 2
Video 2
(KLV-32/26T400A/
26T400G only)
Connect to the video jack 2, and the audio jacks 2. If you connect mono
equipment, connect to the L(MONO) jack 2.
B 1, and 1
Video 1
(KLV-32/26T400A/
26T400G)
Video
(KLV-19T400A/
19T400G/
19T400W)
Connect to the video jack 1, and the audio jacks 1. If you connect mono
equipment, connect to the L(MONO) jack 1.
C / Connect to the video output jack to record the image from the TV. Connect to the
audio output jacks to record the sound from the TV on DVD recorder or VCR. To
turn off the sound of the TV speakers, set “Speaker” to “Audio System” (page 28). If
you connect mono equipment, connect to the L jack .
• The monitor output jacks cannot support HD/DVD, HDMI and PC signals source
pictures, also digital audio signal for sound.
D /
HD/DVD
Connect to the component jacks and the audio jacks / . For better picture quality,
component connection is recommended if your DVD player has a component video
output.
E PC IN (RGB)/
PC
Connect to the PC IN (RGB) jack and the audio jack . It is recommended to
use a PC cable with ferrite core.
F HDMI IN/
HDMI
Connect to the HDMI IN jack if the equipment has an HDMI jack. The digital video
and audio signals are input from the equipment.
For equipment with DVI jack, connect the DVI jack to the HDMI IN jack using a DVI-
HDMI adaptor interface (not supplied). Then, connect the equipment’s audio out jack
to the audio in jack of the HDMI IN.
• The HDMI jack only support the following video inputs: 480i, 480p, 576i, 576p,
720p (50/60 Hz), 1080i (50/60 Hz) and 1080p (50/60 Hz).
• Be sure to use only an HDMI cable that bears the HDMI logo (recommended
Sony HDMI cable).
• To connect a PC, use the PC IN jack.
