8-6
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Not all of the parts for POWER BLOCK
(HS13S0E, HS13S0F, HS13S0U and TOP-
244U) are listed.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
• Abbreviation
AR : Argentina
BR : Brazilian
CND : Canadian
MX : Mexican
8-2. ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
The components identified by mark
0 or dotted line with mark 0 are
critical for safety.
Replace only with part number speci-
fied.
Les composants identifiés par une
marque 0 sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
When indicating parts by reference
number, please include the board.
• Description about model name
DPX14xxBJ
Name of production country
J : Japan
M : Malaysia
Color of set
B : Black
H : Titanium gray
AI-23
* A-6065-642-A AI-23 BOARD, COMPLETE (US (DPX1410BJ),
CND (DPX1410BJ))
* A-6065-664-A AI-23 BOARD, COMPLETE (US (DPX1410BM),
CND (DPX1410BM), E, MX, AR)
* A-6065-668-A AI-23 BOARD, COMPLETE (AEP, UK)
* A-6065-707-A AI-23 BOARD, COMPLETE (BR)
*********************
(Ref.No. 1,000 Series)
3-067-239-11 HOLDER, FL (US (DPX1410BJ),
CND(DPX1410BJ), BR)
3-067-239-01 HOLDER, FL (US (DPX1410BM),
CND (DPX1410BM), AEP, UK, E, MX, AR)
< BUZZER >
BZ401 1-529-986-11 BUZZER, VOLTAGE
< CAPACITOR >
C101 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C102 1-104-664-11 ELECT 47uF 20% 16V
C109 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C110 1-104-664-11 ELECT 47uF 20% 16V
C111 1-104-664-11 ELECT 47uF 20% 16V
C112 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C113 1-104-664-11 ELECT 47uF 20% 16V
C114 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C202 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C203 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C204 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C205 1-164-218-11 CERAMIC CHIP 180PF 5% 50V
C206 1-164-218-11 CERAMIC CHIP 180PF 5% 50V
C207 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C208 1-164-218-11 CERAMIC CHIP 180PF 5% 50V
C209 1-164-218-11 CERAMIC CHIP 180PF 5% 50V
C210 1-104-664-11 ELECT 47uF 20% 16V
C212 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C213 1-126-960-11 ELECT 1uF 20% 50V
C214 1-104-664-11 ELECT 47uF 20% 16V
C215 1-104-664-11 ELECT 47uF 20% 16V
C216 1-126-960-11 ELECT 1uF 20% 50V
(AEP, UK)
C217 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C218 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C225 1-104-664-11 ELECT 47uF 20% 16V
C226 1-104-664-11 ELECT 47uF 20% 16V
C227 1-104-664-11 ELECT 47uF 20% 16V
C228 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
(AEP, UK)
C229 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
(AEP, UK)
C305 1-126-767-11 ELECT 1000uF 20% 16V
C306 1-126-960-11 ELECT 1uF 20% 50V
C309 1-126-924-11 ELECT 330uF 20% 6.3V
C313 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
(AEP, UK)
C314 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
(AEP, UK)
C315 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
(AEP, UK)
C316 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
(AEP, UK)
C317 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
(AEP, UK)
C319 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C320 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C321 1-163-131-00 CERAMIC CHIP 390PF 5% 50V
C322 1-163-131-00 CERAMIC CHIP 390PF 5% 50V
C323 1-164-217-11 CERAMIC CHIP 150PF 5% 50V
C324 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C325 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C326 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C327 1-104-664-11 ELECT 47uF 20% 16V
C328 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C329 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C330 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C331 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C332 1-163-131-00 CERAMIC CHIP 390PF 5% 50V
C333 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C334 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C335 1-163-131-00 CERAMIC CHIP 390PF 5% 50V
C336 1-164-217-11 CERAMIC CHIP 150PF 5% 50V
