2-14. CIRCUIT BOARDS LOCATION
2-5 E
ER-15 (AEP, UK)
(EURO AV)
AI-23
(AUDIO/VIDEO OUT,
INTERFACE CONTROL)
MS-81
(LOADING)
Power Block (TOP-244U)
(US, Canadian)
Power Block (HS13S0U)
(US, Canadian, Mexican)
Power Block (HS13S0E)
(AEP, UK, Argentina)
Power Block (HS13S0F)
(E, Brazilian)
(SWITCHING REGULATOR)
MB-98
(SIGNAL PROCESS, SERVO)
