Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HT-NT5
71
< VARISTOR >
0 VDR901 1-811-165-31 VARISTOR (TVR10471-D) (Except EA)
(See Note 1)
0 VDR901 1-812-256-31 VARISTOR (TVR10561-D) (EA) (See Note 1)
*************************************************************
A-2089-310-A REPEATER BOARD, COMPLETE
*************************
< CONNECTOR >
* CN1100 1-580-055-21 PIN, CONNECTOR (SMD) 2P
< LED >
D1100 6-503-658-01 LED SIM-013ST (IR TRANSMITTER)
D1101 6-503-658-01 LED SIM-013ST (IR TRANSMITTER)
*************************************************************
SIRCS BOARD
***********
< CONNECTOR >
CN891 1-770-620-21 PIN, CONNECTOR 3P
< IC >
IC891 6-600-766-01 IC PNA4823M01S0
*************************************************************
TOUCH BOARD
************
< CONNECTOR >
CN1901 1-816-654-61 FFC/CONNECTOR, FPC (LIF) 6P
< FERRITE BEAD >
FB001 1-481-253-21 FERRITE, EMI (SMD) (1005)
< IC >
IC1901 6-722-496-01 IC CY8CMBR3108-LQXIT
IC1902 6-719-198-01 IC MM3411A33URE
*************************************************************
USB-CHUKEI BOARD
****************
< CONNECTOR >
CN1401 1-569-775-21 PIN, CONNECTOR (SMD) 5P
CN1402 1-822-423-11 CONNECTOR, USB (A) (
)
CN1451 1-770-623-21 PIN, CONNECTOR 6P
CN1453 1-820-899-21 CONNECTOR, FFC/FPC 6P
< DIODE >
D1401 6-500-400-01 DIODE BAV99-215
D1402 6-500-400-01 DIODE BAV99-215
< FERRITE BEAD >
FB1401 1-481-464-11 BEAD, FERRITE (1608)
FB1402 1-481-464-11 BEAD, FERRITE (1608)
TOUCH USB-CHUKEI
< COMPOSITION CIRCUIT BLOCK >
RB1401 1-234-371-11 RES, NETWORK 47 (1005X4)
*************************************************************
MISCELLANEOUS
**************
0 AC1 1-834-966-42 POWER-SUPPLY CORD (SP)
0 AC1 1-835-068-21 CORD, POWER (AUS)
0 AC1 1-835-706-23 CORD, POWER-SUPPLY (BR)
0 AC1 1-837-308-12 CORD, POWER-SUPPLY (US, CND)
0 AC1 1-837-312-11 CORD, POWER-SUPPLY (AR)
0 AC1 1-837-345-11 CORD, POWER-SUPPLY (TW)
0 AC1 1-837-822-21 CORD, POWER-SUPPLY (CH)
0 AC1 1-839-986-12 POWER-SUPPLY CORD (AEP, RU, LA)
0 AC1 1-839-999-22 POWER-SUPPLY CORD (UK, EA)
0 ACP1 1-844-323-11 ADAPTOR, CONVERSION PLUG 3P (SV)
(SP for Hong Kong only) (See Note 5)
0 ACP2 1-569-008-33 ADAPTOR, CONVERSION 2P (AC plug adaptor)
(LA)
FFC1 9-833-607-27 WIRE KIT (BAR FFC) (24P) (See Note 2)
FFC2 9-833-607-27 WIRE KIT (BAR FFC) (18P) (See Note 2)
FFC3 9-833-607-27 WIRE KIT (BAR FFC) (6P) (See Note 2)
FFC4 9-833-607-27 WIRE KIT (BAR FFC) (6P) (See Note 2)
FFC5 9-833-607-27 WIRE KIT (BAR FFC) (26P) (See Note 2)
OLED1 1-812-049-11 ELEMENT, ORGANIC EL INDICATOR
RF1 1-492-347-11 RF MODULATOR (SWA12-4V TX) (See Note 3)
SP1 1-859-142-11 LOUDSPEAKER (50 mm) (Woofer (L-ch))
SP2 1-859-142-11 LOUDSPEAKER (50 mm) (Woofer (R-ch))
SP3 1-859-144-11 LOUDSPEAKER (14-20 mm) (Front tweeter (L-ch))
SP4 1-859-148-11 LOUDSPEAKER (14-20 mm) (Top tweeter (L-ch))
SP5 1-859-148-11 LOUDSPEAKER (14-20 mm) (Top tweeter (R-ch))
SP6 1-859-144-11 LOUDSPEAKER (14-20 mm) (Front tweeter (R-ch))
WIFI1 1-493-092-21 CARD, WLAN/BT COMBO
(Wi-Fi/Bluetooth module) (See Note 4)
WR1 1-971-185-11 HARNESS, COAXIAL (BLACK)
WR2 1-971-187-11 HARNESS, COAXIAL (GRAY)
WR3 1-971-186-11 HARNESS, COAXIAL (WHITE)
*************************************************************
ACCESSORIES
************
4-586-135-14 MANUAL, INSTRUCTION
(ENGLISH, SPANISH, FRENCH) (US, CND)
4-586-135-33 MANUAL, INSTRUCTION (ENGLISH) (AUS)
4-586-135-44 MANUAL, INSTRUCTION
(FRENCH, SPANISH, DUTCH) (AEP)
4-586-135-54 MANUAL, INSTRUCTION
(GERMAN, ITALIAN, PORTUGUESE) (AEP)
4-586-135-62 MANUAL, INSTRUCTION
(ENGLISH, TRADITIONAL CHINESE) (SP, TW)
4-586-135-72 MANUAL, INSTRUCTION (RUSSIAN) (RU)
4-586-135-82 MANUAL, INSTRUCTION (SPANISH) (LA)
Note 3: When the RF modulator (Ref. No. RF1) is replaced, refer
to “WIRELESS CONNECTION (LINK) WORK OF BAR
SPEAKER AND SUBWOOFER” on page 7.
Note 4: When the WLAN/BT combo card (Ref. No. WIFI1) is re-
placed, refer to “NOTE OF REPLACING THE MB-1509
BOARD OR WLAN/BT COMBO CARD” on page 5.
Note 2: As for WIRE KIT (BAR FFC), all fl at fl exible cables (Ref.
No. FFC1, FFC2, FFC3, FFC4, FFC5) will be 1 set.
Note 5: Ref. No. ACP1 is a service part used only for the SP model
sold in Hong Kong.
REPEATER SIRCS
Ver. 1.2
Note 1: When the VDR901 on the POWER board is replaced, refer to
“BOND FIXED POSITION OF ELECTRICAL PARTS” on
page 8.
POWER
To Next Page
