HT-S500RF/S700RF
40
Sony CONFIDENTIAL
For Authorized Servicer
Pin No. Pin Name I/O Description
1 AVDD12_2 - Power supply terminal (+1.2V)
2 AVDD33_1 - Power supply terminal (+3.3V)
3 XTALI I System clock input terminal
4 XTALO O System clock output terminal
5 V14 - Ground terminal
6 GPO5 - Not used
7 AVDD33_2 - Power supply terminal (+3.3V)
8, 9 NC - Not used
10 GPIO2 I Fault signal input terminal (for USB)
11 USB_DP I/O Two-way USB data (+) bus terminal
12 USB_DM I/O Two-way USB data (–) bus terminal
13 VDD33_USB - Power supply terminal (+3.3V)
14 PAD_VRT - Ground terminal
15 VDD12_USB - Power supply terminal (+1.2V)
16 DV_Y2 I ARC SPDIF signal input terminal (for HDMI)
17 DV_Y3 I Optical SPDIF signal input terminal
18 DV_Y4 - Not used
19 SF_CS O Chip select signal output terminal (for serial fl ash)
20 SF_DO O Data output terminal (for serial fl ash)
21 SF_DI I Data input terminal (for serial fl ash)
22 DVDD33 - Power supply terminal (+3.3V)
23 SF_CK O Clock signal output terminal (for serial fl ash)
24 UP1_6/SCL I/O Two-way serial clock signal terminal (for HDMI)
25 UP1_7/SDA I/O Two-way serial data bus terminal (for HDMI)
26 GPIO11 I Serial data input terminal (for DSP)
27 GPIO6 O Serial data output terminal (for DSP)
28 PRST_ I Reset signal input terminal
29 IR_ I IR control signal input terminal
30 GPIO3/INT_ I/O Two-way CEC serial data bus terminal (for HDMI)
31 GPIO4 O Bluetooth on/off control signal output terminal
32 DV_C0 O Power on/off control signal output terminal
33 DV_C1 O I2S data selection signal output terminal
34 DV_C2 O MCU control signal output terminal
35 DV_C3 - Not used
36 SD_MS_D2 I MCU data input terminal
37 SD_MS_D3 O MCU data output terminal
38 GPIO13 O I2S data selection signal output terminal
39 GPIO9 I/O Two-way CEC serial data bus terminal (for HDMI)
40 GPIO8 O IR enable signal output terminal
41 GPIO7/CKE_ I/O Two-way interrupt signal terminal (for touch key)
42 DVDD33 - Power supply terminal (+3.3V)
43 to 50 RD0 to RD7 I/O Two-way data bus terminal
51 DQM0 O Data mask signal output terminal
52, 53 RD15, RD14 I/O Two-way data bus terminal
54 DVDD12 - Power supply terminal (+1.2V)
55 to 60 RD13 to RD8 I/O Two-way data bus terminal
61 DQM1 O Data mask signal output terminal
62 RCLK O Clock signal output terminal
63 to 66 RA11, RA9 to RA7 O Address signal output terminal
67 DVDD33 - Power supply terminal (+3.3V)
68 to 70 RA6 to RA4 O Address signal output terminal
71 RWE_ O Write enable signal output terminal
72 CAS_ O Column address strobe signal output terminal
73 RAS_ O Row address strobe signal output terminal
74 DVDD33 - Power supply terminal (+3.3V)
75, 76 BA0, BA1 O Bank address signal output terminal
77 to 81 RA10, RA0 to RA3 O Address signal output terminal
82 DVDD12 - Power supply terminal (+1.2V)
MAIN BOARD U7 MT8301OXE (DIGITAL AUDIO INTERFACE RECEIVER, DSP)
