HT-S500RF/S700RF
41
Sony CONFIDENTIAL
For Authorized Servicer
Pin No. Pin Name I/O Description
83 SPDIF/GPIO12 - Not used
84 GPIO10/HPLG I Hot plug detection signal input terminal (for HDMI)
85 EXT_RES - Ground terminal
86 AVDD33_12 - Power supply terminal (+3.3V)
87 TXCN I TMDS clock (negative) signal input terminal (for HDMI)
88 TXCP I TMDS clock (positive) signal input terminal (for HDMI)
89 AVDD12_C - Power supply terminal (+1.2V)
90 TX0N I TMDS data (negative) input terminal (for HDMI)
91 TX0P I TMDS data (positive) input terminal (for HDMI)
92 AVSS12 - Ground terminal
93 TX1N I TMDS data (negative) input terminal (for HDMI)
94 TX1P I TMDS data (positive) input terminal (for HDMI)
95 AVDD12_D - Power supply terminal (+1.2V)
96 TX2N I TMDS data (negative) input terminal (for HDMI)
97 TX2P I TMDS data (positive) input terminal (for HDMI)
98 GPIO29 - Not used
99 GPIO30 I/O Two-way I2C serial data bus terminal
100 GPIO31 O I2C serial clock signal output terminal
101, 102 GPIO32, GPIO33 - Not used
103 AVDD33 - Power supply terminal (+3.3V)
104 VREF/GPIO14 O Muting signal output terminal (for AMP)
105 FS - Ground terminal
106 NC - Not used
107 AVDD33 - Power supply terminal (+3.3V)
108 AGND33 - Power supply terminal (+3.3V)
109, 110 NC - Not used
111 AKIN2/GPIO19 I Audio data input terminal
112 ADVCM/GPIO20 O Enable signal output terminal (for USB)
113 AKIN1/GPIO21 - Not used
114 AADVDD - Power supply terminal (+3.3V)
115
APLLVDD_GPIO/
GPIO34
- Not used
116 APLLCAP/GPIO35 O MCU and VFD control signal output terminal
117 ADACVSS - Ground terminal
118 LFE/GPIO O Master clock signal output terminal
119 ABCK O Bit clock signal output terminal
120 AR/GPIO0 O Audio data output terminal
121 AVCM - Ground terminal
122 AL/GPIO O Audio data output terminal
123 ALRCK O L/R sampling clock signal output terminal
124 ASDATA0 O Audio data output terminal
125, 126 ADACVDD1, ADACVDD2 - Power supply terminal (+3.3V)
127 AVDD12 - Power supply terminal (+1.2V)
128 NC - Not used
129 E-PAD/GND - Ground terminal
