8-3
C3522 1-162-294-31 CERAMIC 0.001uF 10% 50V
C3523 1-126-301-11 ELECT 1uF 20% 50V
C3524 1-102-129-00 CERAMIC 10000PF 10% 50V
C3525 1-124-465-00 ELECT 0.47uF 20% 50V
C3526 1-130-494-11 MYLAR 0.082uF 5% 50V
C3536 1-126-335-11 ELECT 220uF 20% 6.3V
C3540 1-164-073-11 CERAMIC 100PF 10% 50V
C3551 1-136-166-00 FILM 0.12uF 5% 50V
(EXCEPT E220UY)
C3551 1-136-171-00 FILM 0.33uF 5% 50V
(E220UY)
C3552 1-162-217-31 CERAMIC 56PF 5% 50V
C3553 1-126-301-11 ELECT 1uF 20% 50V
C3554 1-162-284-31 CERAMIC 150PF 10% 50V
C3555 1-102-129-00 CERAMIC 10000PF 10% 50V
C3556 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C3558 1-124-229-00 ELECT 33uF 20% 10V
C3570 1-161-063-00 CERAMIC 0.1uF 10% 50V
C3571 1-161-063-00 CERAMIC 0.1uF 10% 50V
C3581 1-136-169-00 FILM 0.22uF 5% 50V
(E220UY)
! C5001 1-136-188-11 FILM 0.068uF 5% 250V
! C5002 1-136-188-11 FILM 0.068uF 5% 250V
! C5005 1-115-383-11 CERAMIC 0.001uF 10% 125V
! C5007 1-115-385-11 CERAMIC 0.0022uF 20% 400V
C5010 1-125-554-11 ELECT 47uF 20% 400V
C5011 1-124-259-11 ELECT 4.7uF 20% 50V
C5012 1-110-974-11 CAPACITOR 3300PF 500V
C5013 1-104-596-11 CAPACITOR 39PF
C5015 1-161-772-11 CERAMIC 0.1uF 10% 25V
C5017 1-164-080-11 CERAMIC 390PF 10% 50V
C5020 1-115-678-11 CAPACITOR 47PF
C5021 1-110-973-11 CAPACITOR 2200PF
C5025 1-104-596-11 CAPACITOR 39PF
C5101 1-124-525-11 ELECT 1000uF 20% 25V
C5102 1-126-916-11 ELECT 1000uF 20% 6.3V
C5103 1-126-935-11 ELECT 470uF 20% 16V
C5104 1-124-525-11 ELECT 1000uF 20% 25V
C5105 1-124-910-11 ELECT 47uF 20% 50V
C5106 1-126-947-11 ELECT 47uF 20% 35V
C5107 1-126-176-11 ELECT 220uF 20% 10V
C5111 1-124-455-00 ELECT 100uF 20% 16V
C5112 1-111-241-11 ELECT 10uF 20% 16V
C5113 1-126-162-11 ELECT 3.3uF 20% 50V
C5114 1-111-241-11 ELECT 10uF 20% 16V
C5115 1-126-162-11 ELECT 3.3uF 20% 50V
C5116 1-111-241-11 ELECT 10uF 20% 16V
C5117 1-126-162-11 ELECT 3.3uF 20% 50V
C5118 1-111-241-11 ELECT 10uF 20% 16V
C5124 1-124-464-11 ELECT 0.22uF 20% 50V
C5134 1-104-643-11 CERAMIC 330PF 20% 25V
C5135 1-130-495-11 MYLAR 0.1uF 5% 50V
< CONNECTOR >
CN231 1-251-522-11 SOCKET, RGB (21P)
CN301 1-251-523-11 SOCKET, FFC (37P)
! CN501 1-251-483-11 SOCKET, AC INLET
< DIODE >
D1001 8-719-991-33 DIODE 1SS133T-77 (E120AE,E220 Series)
D1002 8-719-991-33 DIODE 1SS133T-77 (E120AE,E220 Series)
D1003 8-719-991-33 DIODE 1SS133T-77
D1301 8-719-991-33 DIODE 1SS133T-77
D1302 8-719-991-33 DIODE 1SS133T-77
D1303 8-719-991-33 DIODE 1SS133T-77
(E270CP,VC1,VC2,E280CP,VC1,VC2)
D1304 8-719-991-33 DIODE 1SS133T-77
(E270CP,VC1,VC2,E280CP,VC1,VC2)
D1341 8-719-991-33 DIODE 1SS133T-77
(E120AE,E220 Series,E280UX)
D1342 8-719-991-33 DIODE 1SS133T-77
(E120AE,E220 Series,E280UX)
D1343 8-719-991-33 DIODE 1SS133T-77 (E280UX)
D1344 8-719-991-33 DIODE 1SS133T-77 (E280UX)
D1345 8-719-109-88 DIODE RD5.6ES-B1
(E270CP,VC1,VC2,E280CP,VC1,VC2)
D1346 8-719-109-88 DIODE RD5.6ES-B1
(E270CP,VC1,VC2,E280CP,VC1,VC2)
D2341 8-719-991-33 DIODE 1SS133T-77
D2371 8-719-110-41 DIODE RD15ES-B2
D2372 8-719-109-88 DIODE RD5.6ES-B1 (E280CP,VC1,VC2)
D2373 8-719-110-41 DIODE RD15ES-B2 (E280CP,VC1,VC2)
D2374 8-719-109-88 DIODE RD5.6ES-B1 (E280CP,VC1,VC2)
D3001 8-719-991-33 DIODE 1SS133T-77
D3102 8-719-991-33 DIODE 1SS133T-77
D3103 8-719-991-33 DIODE 1SS133T-77 (E120AE)
D3104 8-719-991-33 DIODE 1SS133T-77 (E220UY,E280UX)
D3106 8-719-991-33 DIODE 1SS133T-77
(E270CP,VC1,VC2,E280Series)
D3107 8-719-991-33 DIODE 1SS133T-77 (E280 Series)
D3108 8-719-991-33 DIODE 1SS133T-77
(E270CP,VC1,VC2,E280CP,VC1,VC2)
D3111 8-719-991-33 DIODE 1SS133T-77 (E220UY,E280UX)
D3112 8-719-991-33 DIODE 1SS133T-77 (E220UY,E280UX)
D3115 8-719-991-33 DIODE 1SS133T-77
(E220VP1,VP2,E270VC1,VC2,E280UX,VC1,VC2)
D3116 8-719-991-33 DIODE 1SS133T-77 (E280UX)
D3117 8-719-991-33 DIODE 1SS133T-77 (E120AE,E220 Series)
D3118 8-719-991-33 DIODE 1SS133T-77
(E220UY,E270CP,VC1,VC2,E280 Series)
D3123 8-719-991-33 DIODE 1SS133T-77
(E270CP,VC1,VC2,E280 Series)
D3124 8-719-991-33 DIODE 1SS133T-77 (E220UY,E280 Series)
D3401 8-719-982-27 DIODE MTZJ-T-77-33C
(EXCEPT E220UY,E280UX)
D3502 8-719-991-33 DIODE 1SS133T-77
D3554 8-719-991-33 DIODE 1SS133T-77 (E270 & E280 Series)
D5001 1-801-646-11 DIODE DB105G-S
D5003 8-719-901-83 DIODE 1SS83
D5004 8-719-901-83 DIODE 1SS83
D5006 8-719-901-83 DIODE 1SS83
D5010 1-808-898-11 DIODE AP0IC-V0
! D5013 1-810-884-11 DIODE PHOTO COUPLER PC123U2
D5101 1-810-795-11 DIODE RL2Z-LF-C4
D5102 1-810-795-11 DIODE RL2Z-LF-C4
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
––––––– ––––––– –––––––––– ––––––– ––––––– ––––––– –––––––––– ––––––
CP-A
The components identified by mark !
or dotted line with mark ! are critical
for safety.
Replace only with part number specified.
When indicating parts by reference
number, please include the board.
