Sony STR-DA5300ES - Page 126

126126
STR-DA5300ES
STR-DA5300ES
• Waveforms
– DIGITAL Board –
1
IC2208 wk (XOUT)
1 V/DIV, 20 ns/DIV
40.7 ns
3.6 Vp-p
ra
IC3850 es (CLKIN_A)
1 V/DIV, 20 ns/DIV
37 ns
3.2 Vp-p
rs
IC3901 wh (OSCOUT)
1 V/DIV, 10 ns/DIV
22.1 ns
3.6 Vp-p
qd
IC5208 tj (XOUT)
1 V/DIV, 50 ns/DIV
80 ns
3.5 Vp-p
qa
IC5002 A2 (XTAL)
1 V/DIV, 50 ns/DIV
81.4 ns
3 Vp-p
326 ns
3.2 Vp-p
rd
IC3901 el (I2SSCLK)
1 V/DIV, 200 ns/DIV
88.6 ns
3.2 Vp-p
rg
IC3901 rd (I2SOCLK)
1 V/DIV, 50 ns/DIV
20.8 µ s
3.2 Vp-p
rf
IC3901 ra (I2SLRCLK)
1 V/DIV, 10 µ s/DIV
qs
IC5202 A2 (XTAL)
1 V/DIV, 20 ns/DIV
40 ns
2.4 Vp-p
rh
IC3511 of (XTALOUT)
1 V/DIV, 20 ns/DIV
35.3 ns
3.8 Vp-p
rj
IC3610 r; (X1)
1 V/DIV, 100 ns/DIV
250 ns
3.4 Vp-p
rk
IC3604 <zvx (XOUT)
1 V/DIV, 20 ns/DIV
30.1 ns
3.8 Vp-p
– DSP Board – – D-VIDEO Board –
IC6202 1 (M.OUT)
(Color bar)
wa
1 V/DIV, 20 µ s/DIV
H
2.2 Vp-p
IC6202 qd (V1.IN)
(Color bar)
ws
500 mV/DIV, 20 µ s/DIV
H
1.1 Vp-p
IC6511 7 (VIN3)
(Color bar)
wd
500 mV/DIV, 20 µ s/DIV
H
1.1 Vp-p
IC6511 qa (VOUT3)
(Color bar)
wf
1 V/DIV, 20 µ s/DIV
H
2.2 Vp-p
wg
IC6511 qd (VOUT2)
(Color bar)
500 mV/DIV, 20 µ s/DIV
1.6 Vp-p
H
wh
IC6511 qg (VOUT1)
(Color bar)
1 V/DIV, 20 µ s/DIV
H
1.9 Vp-p
wj
IC6518 3 (Y)
(Color bar)
500 mV/DIV, 20 µ s/DIV
H
0.9 Vp-p
es
IC6518 qk (Y_OUT)
(Color bar)
1 V/DIV, 20 µ s/DIV
H
1.8 Vp-p
wl
IC6518 7 (Pr)
(Color bar)
200 mV/DIV, 20 µ s/DIV
H
0.6 Vp-p
e;
IC6518 qf (Pr_OUT)
(Color bar)
500 mV/DIV, 20 µ s/DIV
H
1.2 Vp-p
wk
IC6518 5 (Pb)
(Color bar)
200 mV/DIV, 20 µ s/DIV
H
0.6 Vp-p
ea
IC6518 qh (Pb_OUT)
(Color bar)
500 mV/DIV, 20 µ s/DIV
H
1.2 Vp-p
– A-VIDEO Board –
