Sony STR-DA5300ES - 3 Electrical Parts List

23
STR-DA5300ES
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
A-1252-345-A CONTROL BOARD, COMPLETE (US, CND)
A-1252-346-A CONTROL BOARD, COMPLETE (AEP, ECE, UK)
************************
< CAPACITOR >
C2001 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2002 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2003 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2004 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C2005 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2006 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2007 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C2008 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2009 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C2010 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2011 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2012 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C2013 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2014 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2015 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2016 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2017 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2018 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2019 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2020 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2021 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C2022 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C2023 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C2024 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C2025 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C2026 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2027 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C2028 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2029 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C2030 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C2031 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C2032 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2033 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2034 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2035 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C2036 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2037 1-126-382-11 ELECT 100uF 20% 16V
C2038 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2039 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2040 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C2041 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2042 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2043 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C2044 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2045 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2046 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2047 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2048 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C2049 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C2050 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2051 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2052 1-126-960-11 ELECT 1uF 20% 50V
C2053 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2054 1-126-964-11 ELECT 10uF 20% 50V
C2055 1-119-941-91 ELECT 470uF 20% 6.3V
C2056 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2057 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2058 1-126-382-11 ELECT 100uF 20% 16V
C2059 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2060 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C2061 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2062 1-126-785-11 ELECT 47uF 20% 10V
C2063 1-104-658-91 ELECT 100uF 20% 10V
C2064 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2065 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2066 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C2067 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN2001 1-770-385-11 CONNECTOR, BOARD TO BOARD 18P
CN2003 1-770-406-11 CONNECTOR, BOARD TO BOARD 10P
CN2004 1-770-409-11 CONNECTOR, BOARD TO BOARD 16P
CN2005 1-770-410-11 CONNECTOR, BOARD TO BOARD 18P
CN2006 1-770-411-11 CONNECTOR, BOARD TO BOARD 20P
CN2007 1-785-125-21 CONNECTOR 6P
CN2008 1-770-406-11 CONNECTOR, BOARD TO BOARD 10P
CN2009 1-770-385-11 CONNECTOR, BOARD TO BOARD 18P
CN2010 1-770-383-11 CONNECTOR, BOARD TO BOARD 14P
CN2011 1-770-384-21 CONNECTOR, BOARD TO BOARD 16P
CN2012 1-784-930-11 PIN, CONNECTOR 15P
CN2013 1-779-799-11 PIN, CONNECTOR 9P
CN2014 1-784-928-11 PIN, CONNECTOR 13P
3. ELECTRICAL PARTS LIST
When indicating parts by reference number,
please include the board.
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS
uF: µF
• COILS
uH: µH
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• SEMICONDUCTORS
In each case, u: µ, for example:
uA... : µA... uPA... : µPA...
uPB... : µPB... uPC... : µPC...
uPD... : µPD...
• Abbreviation
CND : Canadian model
ECE : Russian and Ukrainian models
CONTROL
