STR-DA5300ES
Frequency response
Inputs (Analog)
Inputs (Digital)
Outputs
EQUALIZER
FM tuner section
Tuning range 87.5 − 108.0 MHz
Antenna (aerial) FM wire antenna (aerial)
Antenna (aerial) terminals
75 ohms, unbalanced
AM tuner section
T
(US and Canadian models)
uning range
With 10-kHz tuning scale
530 − 1,710 kHz
3)
(AEP, Russian, Ukrainian and UK models)
With 9-kHz tuning scale
531 − 1,602 kHz
With 9-kHz tuning scale
531 − 1,710 kHz
3)
Antenna (aerial) Loop antenna (aerial)
3)
You can change the AM tuning scale to either 9
kHz or 10 kHz. After tuning in any AM station,
turn off the receiver. While holding down
TUNING MODE, press POWER on the receiver.
All preset stations will be erased when you change
the tuning scale. To reset the scale to 10 kHz (or 9
kHz), repeat the procedure.
Video section
Inputs/Outputs
Video: 1 Vp-p, 75 ohms
COMPONENT VIDEO:
Y: 1 Vp-p, 75 ohms
P
B
/C
B
: 0.7 Vp-p, 75 ohms
P
R
/C
R
: 0.7 Vp-p, 75 ohms
80 MHz HD Pass Through
HDMI Video
Input/Output (HDMI Repeater block)
640 × 480p@60Hz
720 × 480p@59.94/60Hz
1440 × 480p@59.94/60Hz (pixel sent 2times)
1280 × 720p@59.94/60Hz
1920 × 1080i@59.94/60Hz
1920 × 1080p@59.94/60Hz
720 × 576p@50Hz
1440 × 576p@50Hz (pixel sent 2times)
1280 × 720p@50Hz
1920 × 1080i@50Hz
1920 × 1080p@50Hz
1920 × 1080p@24Hz
PHONO RIAA equalization curve
± 0.5 dB
MULTI CHANNEL
INPUT, SA-CD/CD,
MD/DAT, DVD/BD,
T
TAPE/CD-R,
TAPE/CD-R,
V, SAT/CATV,
VIDEO 1/2/3
10 Hz − 100 kHz
± 3 dB
PHONO Sensitivity: 2.5mV
Impedance: 50kohms
S/N: 90dB (A, 20 kHz
LPF)
MULTI CHANNEL
INPUT, SA-CD/CD,
MD/DAT, DVD/BD, TV,
SAT/CATV,
VIDEO 1/2/3
Sensitivity: 150mV
Impedance: 50kohms
S/N: 100dB (A, 20 kHz
LPF)
DVD/BD, VIDEO 2,
SA-CD/CD (Coaxial)
Impedance: 75ohms
S/N: 96dB (A, 20 kHz
LPF)
VIDEO 1, TV,
SAT/CATV,
TAPE /C DR,
MD/DAT (Optical)
S/N: 96 dB
(A, 20 kHz LPF)
MD/DAT (REC OUT),
VIDEO 1, ZONE 2,
ZONE 3 (AUDIO OUT)
Vo l tage:150mV
Impedance: 1kohm
FRONT L/R, CENTER,
SURROUND L/R,
SURROUND BACK L/R,
SUB WOOFER
Vo l tage: 2V
Impedance: 1kohm
Gain levels ±10 dB, 1 dB step
Reference Power Output at Stereo Mode
(4 ohms 1 kHz, THD
10%):
150 W + 150 W
Reference Power Output
(8 ohms 1 kHz, THD 10%)
FRONT
2)
:
150 W + 150 W
CENTER
2)
:
150 W
SURROUND
2)
:
150 W + 150 W
SURROUND BACK
2)
:
150 W + 150 W
Reference Power Output
(4 ohms 1 kHz, THD 10%)
FRONT
2)
:
150 W + 150 W
CENTER
2)
:
150 W
SURROUND
2)
:
150 W + 150 W
SURROUND BACK
2)
:
150 W + 150 W
1)
Depending on the sound field settings and the
source, there may be no sound output.
2)
Measured under the following conditions:
Power requirements: 230 V AC, 50/60 Hz
(in countries/area in Europe
other than the U.K.)
240 V AC, 50/60 Hz
(in the U.K. and general area)
General
Power requirements 120 V AC, 60 Hz (US and
Canadian models)
Power output (DIGITAL MEDIA PORT)
DC OUT:5 V, 700 mA
Power consumption 480 W/580 VA (US/
480 W (AEP, Russian,
Ukrainian and UK models)
Canada)
Power consumption (during standby mode)
0.7 W (when “HDMI
Control” and “RS-232C
Control” is set to “OFF”)
Dimensions 430 × 175 × 430 mm
(width/height/depth)
including projecting parts
and controls
Mass (Approx.) 16.0 kg
Supplied accessories
Operating Instructions
Quick Setup Guide (1)
HDMI CONTROL Guide (1)
GUI Menu List (1)
Optimizer microphone ECM-AC1 (1)
FM wire antenna (aerial) (1)
AM loop antenna (aerial) (1)
AC power cord (mains lead) (1)
Remote commander RM-AAL008 (1) (US and
Canadian models)
Remote commander RM-AAL009 (1) (AEP,
Russian, Ukrainian and UK models)
Remote commander RM-AAU016 (1)
R6 (size-AA) batteries (4)
Design and specifications are subject to
change without notice.
230 V AC, 50/60Hz
(in countries/area in
Europe other than the U.K.)
230 − 240V AC, 50/60Hz
(in the U.K. and general
area)
Ver. 1.1
