Sony STR-DA5300ES - 8. ELECTRICAL PARTS LIST

182
STR-DA5300ES
SECTION 8
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS
uF: µF
• COILS
uH: µH
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• SEMICONDUCTORS
In each case, u: µ, for example:
uA... : µA... uPA... : µPA...
uPB... : µPB... uPC... : µPC...
uPD... : µPD...
• Abbreviation
CND : Canadian model
ECE : Russian and Ukrainian models
When indicating parts by reference number,
please include the board.
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque 0
sont critiquens pour la sécurité.
Ne les remplacer que par une pièce portant le
numéro spécifié.
The components identified by mark 9 contain
confidential information.
Strictly follow the instructions whenever the
components are repaired and/or replaced.
Les composants identifiés par la marque 9
contiennent des informations confidentielles.
Suivre scrupuleusement les instructions
chaque fois qu’un composant est remplacé et /
ou réparé.
A-1252-359-A A-CLASS AMP BOARD, COMPLETE (US, CND)
A-1252-360-A A-CLASS AMP BOARD, COMPLETE (AEP, ECE)
A-1273-357-A A-CLASS AMP BOARD, COMPLETE (UK)
****************************
< CAPACITOR >
C1501 1-112-099-11 ELECT 4.7uF 20% 50V
(AEP, ECE, UK)
C1501 1-126-963-11 ELECT 4.7uF 20% 50V
(US, CND)
C1502 1-128-809-11 CERAMIC 100PF 5% 50V
C1503 1-137-503-11 FILM 100PF 5% 100V
C1504 1-136-357-11 FILM 680PF 5% 100V
C1505 1-104-665-11 ELECT 100uF 20% 25V
(US, CND)
C1505 1-112-090-11 ELECT 100uF 20% 25V
(AEP, ECE, UK)
C1507 1-107-587-11 CERAMIC 7PF 0.5PF 500V
C1508 1-112-421-11 ELECT 330uF 20% 25V
(AEP, ECE, UK)
C1508 1-126-940-11 ELECT 330uF 20% 25V
(US, CND)
C1510 1-112-416-11 ELECT 220uF 20% 16V
(AEP, ECE, UK)
C1510 1-126-934-11 ELECT 220uF 20% 16V
(US, CND)
C1511 1-107-585-11 CERAMIC 5PF 0.25PF 500V
C1515 1-107-585-11 CERAMIC 5PF 0.25PF 500V
C1551 1-112-099-11 ELECT 4.7uF 20% 50V
(AEP, ECE, UK)
C1551 1-126-963-11 ELECT 4.7uF 20% 50V
(US, CND)
C1552 1-128-809-11 CERAMIC 100PF 5% 50V
C1553 1-137-503-11 FILM 100PF 5% 100V
C1554 1-136-357-11 FILM 680PF 5% 100V
C1555 1-104-665-11 ELECT 100uF 20% 25V
(US, CND)
C1555 1-112-090-11 ELECT 100uF 20% 25V
(AEP, ECE, UK)
C1557 1-107-587-11 CERAMIC 7PF 0.5PF 500V
C1558 1-112-421-11 ELECT 330uF 20% 25V
(AEP, ECE, UK)
C1558 1-126-940-11 ELECT 330uF 20% 25V
(US, CND)
C1560 1-112-416-11 ELECT 220uF 20% 16V
(AEP, ECE, UK)
C1560 1-126-934-11 ELECT 220uF 20% 16V
(US, CND)
C1561 1-107-585-11 CERAMIC 5PF 0.25PF 500V
C1565 1-107-585-11 CERAMIC 5PF 0.25PF 500V
C1601 1-112-099-11 ELECT 4.7uF 20% 50V
(AEP, ECE, UK)
C1601 1-126-963-11 ELECT 4.7uF 20% 50V
(US, CND)
C1602 1-128-809-11 CERAMIC 100PF 5% 50V
C1603 1-137-503-11 FILM 100PF 5% 100V
C1604 1-136-357-11 FILM 680PF 5% 100V
C1605 1-104-665-11 ELECT 100uF 20% 25V
(US, CND)
C1605 1-112-090-11 ELECT 100uF 20% 25V
(AEP, ECE, UK)
C1607 1-107-587-11 CERAMIC 7PF 0.5PF 500V
C1608 1-112-421-11 ELECT 330uF 20% 25V
(AEP, ECE, UK)
C1608 1-126-940-11 ELECT 330uF 20% 25V
(US, CND)
C1610 1-112-416-11 ELECT 220uF 20% 16V
(AEP, ECE, UK)
C1610 1-126-934-11 ELECT 220uF 20% 16V
(US, CND)
C1611 1-107-585-11 CERAMIC 5PF 0.25PF 500V
C1615 1-107-585-11 CERAMIC 5PF 0.25PF 500V
C1701 1-112-099-11 ELECT 4.7uF 20% 50V
(AEP, ECE, UK)
C1701 1-126-963-11 ELECT 4.7uF 20% 50V
(US, CND)
C1702 1-128-809-11 CERAMIC 100PF 5% 50V
C1703 1-137-503-11 FILM 100PF 5% 100V
C1704 1-136-357-11 FILM 680PF 5% 100V
C1705 1-104-665-11 ELECT 100uF 20% 25V
(US, CND)
A-CLASS AMP
Ver. 1.1
