STR-DA5300ES
20
3-3. SP-TM BOARD, TUNER (FM/AM)
Note: Follow the disassembly procedure in the numerical order given.
3-2. CASE
3 flat head screw
(TP)
5 case
4
4
1 two screws
(BVST4
× 8 (for black),
BVTT4
× 8 (for silver))
2 two flat head screws
(TP)
1 two screws
(BVST4
× 8 (for black),
BVTT4
× 8 (for silver))
4 tuner (FM/AM)
2 wire (flat type) (9 core)
(US and Canadian models),
wire (flat type) (11 core)
(AEP, Russian, Ukrainian and
UK models) (tuner (FM/AM))
6
8
SP-TM board
7 four connectors
(CX4101, CX4102
CX4103, CX4104)
5 two screws (BV/ring)
3 two screws
(BVTT2.6
× 6)
1 clamp
1 clamp
1 clamp
Ver. 1.1
