3-9. POWER TRANS FORMER (T001), E-VOL BOARD AND MAIN BOARD
2 connector
(CNP02)
7 CONNECTOR 2 board
9 CONNECTOR 1 board
4 four screws
(BVTT4
× 8)
q; wire
(E-VOL board (CN1209),
MAIN board (CN1205))
1 connector
(CN1402)
3 two connectors
(CN1403, CN1408)
5 power transformer
(T001)
qs two screws
(BVTP3
× 8)
qf two screws
(BVTP3
× 8)
qj two screws
(supllied with J1499)
qh E-VOL board
qg bracket (SS)
qg bracket (SS)
ws two wires
(CN1001, CN1004)
w; three screws
(BV/ring)
ql four screws
(BVTP3
× 8)
wa five screws
(BVTP3
× 8)
wd MAIN board
8 two connectors
(CN1207, CN1209)
6 two connectors
(CN1205, CN1206)
qd two connectors
(CN1203, CN1204)
qa wire
(E-VOL board (CN1208),
MAIN board (CN1206))
qk feeder fixed screw
