Sony STR-DA5300ES - Page 133

133
STR-DA5300ES
– E-VOL Board –
IC1203, 1213, 1223, 1233 CXD9725M-HFL
TRIM VOLUME
0-+24dB/
1dB STEP
TRIM VOLUME
0-+24dB/
1dB STEP
5 to 25 DECODER
&
LATCH CIRCUIT
4 to 13 DECODER
&
LATCH CIRCUIT
4 to 16 DECODER
&
LATCH CIRCUIT
24 BIT
SHIFT REGISTER
CIRCUIT
LEVEL SHIFT
CIRCUIT
5 to 25 DECODER
&
LATCH CIRCUIT
4 to 13 DECODER
&
LATCH CIRCUIT
4 to 16 DECODER
&
LATCH CIRCUIT
2VSS
3TRIM
4TRIM
5TRIM
6OUT
7VRGND
9VRIN
8NC
11CS1
10NC
14NC
1NC
12GND
13CLK
26 TRIM
25 TRIM
24 TRIM
23 OUT
22 VRGND
20 VRIN
21 NC
28 NC
18 CS2
19 NC
15 NC
17 LAT
16 DATA
26 VDD
MAIN
VOLUME
0- –95dB/
0.5dB STEP
MAIN
VOLUME
0- –95dB/
0.5dB STEP
– D-VIDEO Board –
IC3508 SN74LV4052APWR
1
2
3
4
5
6
7
8
16
15
14
13
12
11
10
9
2Y0
1Y2
VCC
1Y1
1-COM
1Y0
1Y3
A
B
GND
GND
INH
2Y1
2Y3
2-COM
2Y2
IC3514, 3517 TK73400AU3G0L-C
1VCONT
2VIN
3GND
4VOUT
5FB
VREF
–
+
THERMAL &
OVER CURRENT
PROTECTION
ON/OFF
CONTROL
IC3516 TK11150CSCL-G
IC3608 TK11118CSCL-G
IC3852, 3855 TK11125CSCL-G
CONTROL
CIRCUIT
BANDGAP
REFERENCE
+
–
OVER HEAT &
OVER CURRENT
PROTECTION
1
VCONT
3
NP
2
GND
4
VOUT
5
VIN
