Sony STR-DA5300ES - Page 136

136
STR-DA5300ES
IC3853 SI-3010KM-TL
1VC
TSD
2VIN
3GND
4VOUT
5ADJ
+
–
REF
IC3854 CY2302-SXC-1T
1FBIN
2IN
3GND
4FS0
6 OUT1
5 FS1
8 OUT2
7 VDD
OUTPUT
BUFFER
OUTPUT
BUFFER
/Q
PHASE
DETECTOR
CHARGE
PUMP
LOOP
FILTER
VCO
/2
IC3904 PCM1753DBQR
1
AUDIO
SERIAL
PORT
POWER
SUPPLY
BCK
SYSTEM
CLOCK
2
DATA
3
LRCK
4
DGND
5
NC
6
VCC
15
SERIAL
CONTROL
PORT
ML
14
4x/8x OVERSAMPLING DIGITAL
FILTER & FUNCTION CONTROL
ENHANCED MULTILEVEL
DELTA-SIGMA MODULATOR
D/A
CONVERTER
D/A
CONVERTER
ZERO
DETECT
OUTPUT AMP
& LOW-PASS
FILTER
OUTPUT AMP
& LOW-PASS
FILTER
MC
SYSTEM
CLOCK
MANAGER
16
SCK
13
MD
12
ZEROL/NA
11
ZEROR/ZEROA
9
AGND
7
VOUTL
8
VOUTR
10
VCOM
IC3905 BA00BC0WFP-E2
THERMAL
SHUT DOWN
OVER CURRENT
PROTECT
VDD
VCC
2
GND
3
NC
5
OUT
4
CTL
1
–
+
VREF
DRIVER
