Pin No. Pin Name I/O Description
140
VIDEO-UCOM
_V/M
I Serial data input from the video system controller
141
VIDEO-UCOM
_M/V
O Serial data output to the video system controller
142
VIDEO-UCOM
_BUSY
O Busy signal output to the video system controller
143
D-M_DATA I Serial data input from the DSP controller
144
M-D_DATA O Serial data output to the DSP controller
145
NO USE
(DSP_SPICLK)
O Serial data transfer clock signal output terminal Not used
146
VSS - Ground terminal
147
VCC5 - Power supply terminal (+3.3V)
148
SIRIUS_TX I Serial data input from the SIRIUS connector
149
SIRIUS_RX O Serial data output to the SIRIUS connector
150
FL_CLR O Blanking period signal output to the fluorescent indicator tube
151
FL_LAT O Serial data latch pulse signal output to the fluorescent indicator tube
152
FL_DATA O Serial data output to the fluorescent indicator tube
153
FL_CLK O Serial data transfer clock signal output to the fluorescent indicator tube
154
DMPORT_DM/M
I Serial data input from the DMPORT connector
155
DMPORT_M/DM
O Serial data output to the DMPORT connector
156
DMPORT_DET I DMPORT detection signal input terminal
157
9850_INT O Reset signal output to the digital audio processor "L": reset
158
9850_FS O L/R sampling clock signal output to the digital audio processor
159 P15_2/O/T2 -
Not used
160 P15_3/O/T3 -
Not used
161
VSS - Ground terminal
162
VCC5 - Power supply terminal (+3.3V)
163
PROTECTOR I Protect signal input terminal
164 NO USE -
Not used
165
RDS_CLK
I
RDS serial data transfer clock signal input from the tuner (FM/AM)
(AEP, Russian, Ukrainian and UK models only)
166, 167
232C-SEL1,
232C-SEL2
O
Data selection signal output to the data selector
168
FSRATE1 I L/R sampling clock signal input terminal
169
LED-STB O LED drive signal output terminal for ON/STANDBY indicator "H": LED on
170
FSRATE2 I L/R sampling clock signal input terminal
171
LED-DCS O LED drive signal output terminal for Digital Cinema Sound indicator "H": LED on
172
LED-MLT O LED drive signal output terminal MULTI CHANNEL DECODING indicator "H": LED on
173
LED-MLT
-DIMMER
O
LED dimmer control signal output terminal for MULTI CHANNEL DECODING indicator
"H": dimmer on
174
EEPROM_SDA I/O Two-way data bus with the EEPROM
175
EEPROM_SCL O Serial data transfer clock signal output to the EEPROM
176
VCC5 - Power supply terminal (+3.3V)
