Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
190
STR-DA5300ES
C713 1-163-025-11 CERAMIC CHIP 0.001uF 50V
C714 1-163-025-11 CERAMIC CHIP 0.001uF 50V
C717 1-126-947-11 ELECT 47uF 20% 35V
C718 1-126-947-11 ELECT 47uF 20% 35V
C719 1-114-263-91 ELECT 47uF 20% 25V
C720 1-114-263-91 ELECT 47uF 20% 25V
C721 1-163-025-11 CERAMIC CHIP 0.001uF 50V
(US, CND)
C722 1-163-025-11 CERAMIC CHIP 0.001uF 50V
(US, CND)
C725 1-114-263-91 ELECT 47uF 20% 25V
(US, CND)
C726 1-114-263-91 ELECT 47uF 20% 25V
(US, CND)
C727 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
(US, CND)
C728 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
(US, CND)
C729 1-114-263-91 ELECT 47uF 20% 25V
C730 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C731 1-112-085-11 ELECT 1000uF 20% 16V
(US, CND)
C731 1-126-767-11 ELECT 1000uF 20% 16V
(AEP, ECE, UK)
C732 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
< CONNECTOR >
CN601 1-784-926-11 PIN, CONNECTOR 11P
CN602 1-770-409-11 CONNECTOR, BOARD TO BOARD 16P
CN603 1-568-830-11 CONNECTOR, FFC 11P (AEP, ECE, UK)
CN606 1-784-927-11 PIN, CONNECTOR 12P
CN608 1-779-978-11 PIN, CONNECTOR 3P
CN609 1-568-828-11 CONNECTOR, FFC 9P (US, CND)
CN610 1-784-924-11 PIN, CONNECTOR 8P
CN725 1-821-182-11 SOCKET, DIN 8P (SIRIUS) (US, CND)
CN727 1-784-921-11 PIN, CONNECTOR 4P
< DIODE >
D412 8-719-404-50 DIODE MA111-TX
D512 8-719-404-50 DIODE MA111-TX
D641 8-719-404-50 DIODE MA111-TX
D651 8-719-404-50 DIODE MA111-TX
< IC >
IC301 8-759-710-97 IC NJM4565M-D
IC401 6-709-810-01 IC TC9274CNG-015
IC402 6-710-005-01 IC TC9273CFG-004
IC461 8-759-710-97 IC NJM4565M-D
IC501 6-709-810-01 IC TC9274CNG-015
IC600 6-710-004-01 IC TC9274CFG-016
IC611 8-759-710-97 IC NJM4565M-D
IC614 8-759-710-97 IC NJM4565M-D
IC615 8-759-710-97 IC NJM4565M-D
IC616 8-759-710-97 IC NJM4565M-D
IC617 8-759-710-97 IC NJM4565M-D
IC619 8-759-710-97 IC NJM4565M-D
IC622 8-759-710-97 IC NJM4565M-D
IC623 8-759-710-97 IC NJM4565M-D
IC624 8-759-710-97 IC NJM4565M-D (US, CND)
IC643 8-759-710-97 IC NJM4565M-D
IC653 8-759-710-97 IC NJM4565M-D
IC654 6-701-011-01 IC uPC2910T-E1
< JACK >
J605 1-784-920-11 JACK, PIN 6P (PHONO/SA-CD/CD IN, MD/
DAT OUT)
J606 1-784-920-11 JACK, PIN 6P (MD/DAT/TAPE/CD-R IN, TAPE/
D-R OUT)
J607 1-784-920-11 JACK, PIN 6P (SAT/CATV/DVD/BD/VIDEO 2
AUDIO IN)
J608 1-784-429-11 JACK, PIN 4P (VIDEO 1 AUDIO IN, VIDEO 1
AUDIO OUT)
J609 1-784-429-11 JACK, PIN 4P (ZONE 2/ZONE 3 AUDIO OUT)
< JUMPER RESISTOR >
JW672 1-216-295-91 SHORT CHIP 0
JW673 1-216-295-91 SHORT CHIP 0
< COIL >
L730 1-414-493-41 INDUCTOR 4.7mH
< TRANSISTOR >
Q540 8-729-230-49 TRANSISTOR 2SC2712-YG
Q552 8-729-230-49 TRANSISTOR 2SC2712-YG
< RESISTOR >
R411 1-208-437-41 RES-CHIP 1K 2% 1/10W
R412 1-208-437-41 RES-CHIP 1K 2% 1/10W
R413 1-208-437-41 RES-CHIP 1K 2% 1/10W
R414 1-208-437-41 RES-CHIP 1K 2% 1/10W
R415 1-208-437-41 RES-CHIP 1K 2% 1/10W
R416 1-208-437-41 RES-CHIP 1K 2% 1/10W
R417 1-208-437-41 RES-CHIP 1K 2% 1/10W
R419 1-208-437-41 RES-CHIP 1K 2% 1/10W
R420 1-208-437-41 RES-CHIP 1K 2% 1/10W
R421 1-208-437-41 RES-CHIP 1K 2% 1/10W
R422 1-208-526-41 RES-CHIP 47K 2% 1/10W
R423 1-208-526-41 RES-CHIP 47K 2% 1/10W
R424 1-208-526-41 RES-CHIP 47K 2% 1/10W
R425 1-208-526-41 RES-CHIP 47K 2% 1/10W
R426 1-208-526-41 RES-CHIP 47K 2% 1/10W
R427 1-208-526-41 RES-CHIP 47K 2% 1/10W
R428 1-208-526-41 RES-CHIP 47K 2% 1/10W
R431 1-208-445-41 RES-CHIP 2.2K 2% 1/10W
R432 1-216-699-11 METAL CHIP 100K 0.5% 1/10W
R433 1-216-699-11 METAL CHIP 100K 0.5% 1/10W
R434 1-216-633-11 METAL CHIP 180 0.5% 1/10W
R435 1-216-673-11 METAL CHIP 8.2K 0.5% 1/10W
R436 1-216-699-11 METAL CHIP 100K 0.5% 1/10W
R437 1-216-627-11 METAL CHIP 100 0.5% 1/10W
R438 1-216-699-11 METAL CHIP 100K 0.5% 1/10W
R439 1-208-774-11 METAL CHIP 470 0.5% 1/10W
R443 1-208-526-41 RES-CHIP 47K 2% 1/10W
R444 1-216-699-11 METAL CHIP 100K 0.5% 1/10W
R445 1-216-627-11 METAL CHIP 100 0.5% 1/10W
R446 1-208-453-41 RES-CHIP 4.7K 2% 1/10W
R447 1-208-437-41 RES-CHIP 1K 2% 1/10W
ANALOG
Ver. 1.1
To Next Page
