Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
193
STR-DA5300ES
C866 1-216-295-91 SHORT CHIP 0
< CONNECTOR >
CN801 1-770-406-11 CONNECTOR, BOARD TO BOARD 10P
< DIODE >
D801 8-719-404-50 DIODE MA111-TX
D802 8-719-075-86 LED SID307BRTP19 (REMOTE CONTROL
TRANSCEIVER)
D803 8-719-404-50 DIODE MA111-TX
< IC >
IC801 6-600-349-21 IC NJL23H400A
IC802 6-700-587-01 IC TC7W53F (TE12R)
IC861 8-759-470-63 IC NJM2145M-TE2
< JACK >
J801 1-563-330-31 JACK (IR REMOTE IN)
J802 1-563-330-31 JACK (IR REMOTE OUT 1)
J803 1-563-330-31 JACK (IR REMOTE OUT 2)
J821 1-563-330-31 JACK (TRIGGER OUT MAIN)
J831 1-563-330-31 JACK (TRIGGER OUT ZONE 2)
J841 1-563-330-31 JACK (TRIGGER OUT ZONE 3)
J861 1-563-330-31 JACK (CTRL S OUT)
J862 1-563-330-31 JACK (CTRL S IN)
< JUMPER RESISTOR >
JW861 1-216-864-11 SHORT CHIP 0
< TRANSISTOR >
Q821 8-729-037-13 TRANSISTOR KTA1271Y
Q822 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q831 8-729-037-13 TRANSISTOR KTA1271Y
Q832 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q841 8-729-037-13 TRANSISTOR KTA1271Y
Q842 8-729-027-43 TRANSISTOR DTC114EKA-T146
< RESISTOR >
R801 1-216-833-11 METAL CHIP 10K 5% 1/10W
R802 1-216-797-11 METAL CHIP 10 5% 1/10W
R803 1-216-845-11 METAL CHIP 100K 5% 1/10W
R804 1-216-833-11 METAL CHIP 10K 5% 1/10W
R805 1-216-845-11 METAL CHIP 100K 5% 1/10W
R806 1-216-809-11 METAL CHIP 100 5% 1/10W
R807 1-216-809-11 METAL CHIP 100 5% 1/10W
R822 1-216-833-11 METAL CHIP 10K 5% 1/10W
R823 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R824 1-216-833-11 METAL CHIP 10K 5% 1/10W
R825 1-216-809-11 METAL CHIP 100 5% 1/10W
R832 1-216-833-11 METAL CHIP 10K 5% 1/10W
R833 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R834 1-216-833-11 METAL CHIP 10K 5% 1/10W
R835 1-216-809-11 METAL CHIP 100 5% 1/10W
R842 1-216-833-11 METAL CHIP 10K 5% 1/10W
R843 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R844 1-216-833-11 METAL CHIP 10K 5% 1/10W
R845 1-216-809-11 METAL CHIP 100 5% 1/10W
R851 1-216-295-91 SHORT CHIP 0
R861 1-216-821-11 METAL CHIP 1K 5% 1/10W
R862 1-216-821-11 METAL CHIP 1K 5% 1/10W
R863 1-216-821-11 METAL CHIP 1K 5% 1/10W
R864 1-216-821-11 METAL CHIP 1K 5% 1/10W
R865 1-216-821-11 METAL CHIP 1K 5% 1/10W
< THERMISTOR >
TH821 1-801-726-11 THERMISTOR, POSITIVE
TH831 1-801-726-11 THERMISTOR, POSITIVE
TH841 1-801-726-11 THERMISTOR, POSITIVE
************************************************************
CONNECTOR 1 BOARD
*******************
< CONNECTOR >
CN1207 1-573-844-11 CONNECTOR, BOARD TO BOARD 12P
CN1209 1-573-844-11 CONNECTOR, BOARD TO BOARD 12P
************************************************************
CONNECTOR 2 BOARD
*******************
< CONNECTOR >
CN1205 1-573-847-11 CONNECTOR, BOARD TO BOARD 15P
CN1206 1-573-847-11 CONNECTOR, BOARD TO BOARD 15P
************************************************************
A-1252-345-A CONTROL BOARD, COMPLETE (US, CND)
A-1252-346-A CONTROL BOARD, COMPLETE (AEP, UK)
************************
< CAPACITOR >
C2001 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2002 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2003 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2004 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C2005 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2006 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2007 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C2008 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2009 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C2010 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2011 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2012 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C2013 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2014 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2015 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2016 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2017 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2018 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2019 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2020 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2021 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C2022 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C2023 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C2024 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C2025 1-162-974-11 CERAMIC CHIP 0.01uF 50V
CONTROLCIS CONNECTOR 2CONNECTOR 1
