Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
201
STR-DA5300ES
FB3604 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3605 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB3606 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB3607 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB3608 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB3609 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB3610 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB3611 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB3612 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB3613 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB3614 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3615 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB3616 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB3901 1-469-152-11 FERRITE, EMI (SMD) (2012) (US, CND)
FB3902 1-414-813-11 FERRITE, EMI (SMD) (2012) (US, CND)
FB3903 1-469-152-11 FERRITE, EMI (SMD) (2012) (US, CND)
< COIL >
* FL3501 1-813-880-11 COMMON MODE CHOKE COIL
* FL3502 1-813-880-11 COMMON MODE CHOKE COIL
* FL3503 1-813-880-11 COMMON MODE CHOKE COIL
* FL3504 1-813-880-11 COMMON MODE CHOKE COIL
< IC >
IC3503 6-711-088-01 IC SII9185CTU
IC3504 6-711-088-01 IC SII9185CTU
IC3508 8-759-596-39 IC SN74LV4052APWR
IC3509 6-704-001-01 IC BR24L02F-WSE2
IC3511 (Not supplied) IC SII9135CTU
IC3513 (Not supplied) IC SII9134CTU
IC3514 6-708-913-01 IC TK73400AU3G0L-C
IC3516 6-705-337-01 IC TK11150CSCL-G
IC3517 6-708-913-01 IC TK73400AU3G0L-C
IC3518 8-759-546-74 IC TC7WH157FU (TE12R)
IC3519 6-706-946-01 IC CXD9850Q
IC3520 8-759-524-09 IC TC74VHC153FT (EL)
IC3521 8-759-524-09 IC TC74VHC153FT (EL)
IC3522 8-759-524-09 IC TC74VHC153FT (EL)
IC3523 8-759-524-09 IC TC74VHC153FT (EL)
IC3524 8-759-548-99 IC SN74LV08APWR
IC3525 8-759-548-99 IC SN74LV08APWR
@ IC3601 6-709-545-01 IC FLI8668-LF-BC
IC3602 6-710-521-11 IC HY5DU561622ETP-4-C
IC3603 6-807-428-11 IC S29GL256N90TFIR20-07GUIX103
IC3604 6-709-564-01 IC YGV629-VZ
IC3605 6-705-468-01 IC BA33BC0FP-E2
IC3607 6-705-468-01 IC BA33BC0FP-E2
IC3608 6-702-300-01 IC TK11118CSCL-G
IC3609 6-707-842-01 IC TC74LCX08FT (EKJ)
IC3610 6-807-445-01 IC MB91F467RA-07A53GUI-X103
IC3611 6-710-003-01 IC IS61LV12816L-8TL
IC3612 6-700-394-01 IC BA25BC0FP-E2
IC3614 6-705-468-01 IC BA33BC0FP-E2
IC3615 6-807-714-01 IC SST39VF3202704IEKE53FLIX105
IC3616 6-705-468-01 IC BA33BC0FP-E2
IC3618 6-710-521-11 IC HY5DU561622ETP-4-C
IC3619 6-710-050-01 IC TC74LCX245FK (EL)
IC3620 6-710-050-01 IC TC74LCX245FK (EL)
IC3621 6-704-573-01 IC M24C32-WMN6T (B)
IC3850 6-709-565-01 IC ADV7322KSTZ
IC3851 6-704-261-01 IC TK11225CMCL-G
IC3852 6-702-301-01 IC TK11125CSCL-G
IC3853 6-705-308-01 IC SI-3010KM-TL
IC3854 6-710-444-01 IC CY2302-SXC-1T
IC3855 6-702-301-01 IC TK11125CSCL-G
IC3901 6-709-251-01 IC F2602E-01-TR (US, CND)
IC3902 6-705-468-01 IC BA33BC0FP-E2 (US, CND)
IC3904 6-707-111-01 IC PCM1753DBQR (US, CND)
IC3905 6-706-740-01 IC BA00BC0WFP-E2 (US, CND)
IC3906 6-705-469-01 IC BA50BC0FP-E2 (US, CND)
IC3907 8-759-710-97 IC NJM4565M-D (US, CND)
< COIL >
L3501 1-469-525-91 INDUCTOR 10uH
L3505 1-469-525-91 INDUCTOR 10uH
L3506 1-469-525-91 INDUCTOR 10uH
L3507 1-469-525-91 INDUCTOR 10uH
L3508 1-469-525-91 INDUCTOR 10uH
L3509 1-469-525-91 INDUCTOR 10uH
L3510 1-469-525-91 INDUCTOR 10uH
L3850 1-469-525-91 INDUCTOR 10uH
< TRANSISTOR >
Q3501 6-550-014-01 FET SSM6N15FU (TE85R)
Q3502 6-550-014-01 FET SSM6N15FU (TE85R)
Q3503 6-550-014-01 FET SSM6N15FU (TE85R)
Q3504 6-550-014-01 FET SSM6N15FU (TE85R)
Q3505 6-550-014-01 FET SSM6N15FU (TE85R)
Q3506 6-550-014-01 FET SSM6N15FU (TE85R)
Q3901 8-729-027-43 TRANSISTOR DTC114EKA-T146 (US, CND)
Q3902 8-729-027-23 TRANSISTOR DTA114EKA-T146 (US, CND)
Q3903 6-550-044-01 TRANSISTOR 2SB1689-T106 (US, CND)
Q3904 8-729-027-43 TRANSISTOR DTC114EKA-T146 (US, CND)
< RESISTOR >
R2038 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3301 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R3302 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R3303 1-216-805-11 METAL CHIP 47 5% 1/10W
R3304 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R3305 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R3306 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R3307 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R3308 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R3309 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R3400 1-216-864-11 SHORT CHIP 0
R3401 1-216-864-11 SHORT CHIP 0
R3402 1-216-864-11 SHORT CHIP 0
R3403 1-216-864-11 SHORT CHIP 0
R3404 1-216-805-11 METAL CHIP 47 5% 1/10W
R3405 1-216-805-11 METAL CHIP 47 5% 1/10W
R3406 1-216-790-11 METAL CHIP 2.7 5% 1/10W
R3407 1-216-805-11 METAL CHIP 47 5% 1/10W
D-VIDEO
Note: IC3511 and IC3513 cannot exchange with single. When
IC3511 and IC3513 are damaged, exchange the entire
mounted board.
@Replacement of IC3601 used in this set requires a
special tool.
