Sony STR-DA5300ES - Page 214

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
214
STR-DA5300ES
FB5204 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB5205 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB5206 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB5207 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB5208 1-469-152-11 FERRITE, EMI (SMD) (2012)
< IC >
IC5001 6-705-308-01 IC SI-3010KM-TL
IC5002 (Not supplied) IC ADSST-AVR-1132
IC5006 6-807-374-04 IC S29AL008D70TFI010-EX4116
IC5007 6-710-529-01 IC IS61LV5128AL-10TLI
IC5009 6-701-992-01 IC SN74LVC573APWR
IC5010 6-701-992-01 IC SN74LVC573APWR
IC5012 6-706-492-01 IC TC7SHU04FU (T5RSOJF)
IC5013 6-707-870-01 IC TC74VHC157FT (EKJ)
IC5201 6-705-308-01 IC SI-3010KM-TL
IC5202 (Not supplied) IC ADSST-AVR-1131
IC5207 6-710-003-01 IC IS61LV12816L-8TL
IC5208 6-807-422-01 IC MB91F353APMT-07A53DSP-X103
IC5209 6-701-992-01 IC SN74LVC573APWR
IC5210 6-701-992-01 IC SN74LVC573APWR
IC5211 8-759-831-52 IC TC7WH125FK (TE85R)
IC5212 8-759-680-48 IC TC7WH157FK (TE85R)
IC5213 6-807-854-01 IC SST25VF040B-07A53J-X101
< RESISTOR >
R5002 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5003 1-216-821-11 METAL CHIP 1K 5% 1/10W
R5004 1-216-857-11 METAL CHIP 1M 5% 1/10W
R5005 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5013 1-216-864-11 SHORT CHIP 0
R5014 1-218-854-11 METAL CHIP 2K 0.5% 1/10W
R5015 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R5016 1-216-864-11 SHORT CHIP 0
R5018 1-216-864-11 SHORT CHIP 0
R5020 1-216-864-11 SHORT CHIP 0
R5021 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5023 1-216-805-11 METAL CHIP 47 5% 1/10W
R5024 1-216-821-11 METAL CHIP 1K 5% 1/10W
R5025 1-216-805-11 METAL CHIP 47 5% 1/10W
R5026 1-216-801-11 METAL CHIP 22 5% 1/10W
R5027 1-216-801-11 METAL CHIP 22 5% 1/10W
R5028 1-216-801-11 METAL CHIP 22 5% 1/10W
R5032 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5035 1-216-857-11 METAL CHIP 1M 5% 1/10W
R5038 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5041 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5042 1-216-864-11 SHORT CHIP 0
R5044 1-216-864-11 SHORT CHIP 0
R5046 1-216-864-11 SHORT CHIP 0
R5047 1-216-864-11 SHORT CHIP 0
R5048 1-216-801-11 METAL CHIP 22 5% 1/10W
R5049 1-216-864-11 SHORT CHIP 0
R5051 1-216-864-11 SHORT CHIP 0
R5052 1-216-864-11 SHORT CHIP 0
R5053 1-216-801-11 METAL CHIP 22 5% 1/10W
R5054 1-216-801-11 METAL CHIP 22 5% 1/10W
R5055 1-216-864-11 SHORT CHIP 0
R5056 1-216-864-11 SHORT CHIP 0
R5057 1-216-864-11 SHORT CHIP 0
R5058 1-216-864-11 SHORT CHIP 0
R5059 1-216-864-11 SHORT CHIP 0
R5060 1-216-801-11 METAL CHIP 22 5% 1/10W
R5061 1-216-801-11 METAL CHIP 22 5% 1/10W
R5062 1-216-801-11 METAL CHIP 22 5% 1/10W
R5063 1-216-801-11 METAL CHIP 22 5% 1/10W
R5064 1-216-801-11 METAL CHIP 22 5% 1/10W
R5065 1-216-801-11 METAL CHIP 22 5% 1/10W
R5066 1-216-801-11 METAL CHIP 22 5% 1/10W
R5067 1-216-801-11 METAL CHIP 22 5% 1/10W
R5068 1-216-821-11 METAL CHIP 1K 5% 1/10W
R5069 1-216-801-11 METAL CHIP 22 5% 1/10W
R5070 1-216-864-11 SHORT CHIP 0
R5071 1-216-864-11 SHORT CHIP 0
R5072 1-216-864-11 SHORT CHIP 0
R5073 1-216-801-11 METAL CHIP 22 5% 1/10W
R5074 1-216-801-11 METAL CHIP 22 5% 1/10W
R5075 1-216-801-11 METAL CHIP 22 5% 1/10W
R5076 1-216-864-11 SHORT CHIP 0
R5077 1-216-864-11 SHORT CHIP 0
R5078 1-216-864-11 SHORT CHIP 0
R5096 1-216-864-11 SHORT CHIP 0
R5097 1-216-801-11 METAL CHIP 22 5% 1/10W
R5098 1-216-801-11 METAL CHIP 22 5% 1/10W
R5202 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5204 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5205 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5208 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5209 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5212 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5213 1-216-864-11 SHORT CHIP 0
R5214 1-218-854-11 METAL CHIP 2K 0.5% 1/10W
R5215 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R5216 1-216-864-11 SHORT CHIP 0
R5218 1-216-864-11 SHORT CHIP 0
R5220 1-216-864-11 SHORT CHIP 0
R5221 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5223 1-216-864-11 SHORT CHIP 0
R5224 1-216-821-11 METAL CHIP 1K 5% 1/10W
R5225 1-216-805-11 METAL CHIP 47 5% 1/10W
R5226 1-216-801-11 METAL CHIP 22 5% 1/10W
R5227 1-216-801-11 METAL CHIP 22 5% 1/10W
R5228 1-216-801-11 METAL CHIP 22 5% 1/10W
R5229 1-216-801-11 METAL CHIP 22 5% 1/10W
R5230 1-216-801-11 METAL CHIP 22 5% 1/10W
R5231 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5232 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5233 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5234 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5235 1-216-857-11 METAL CHIP 1M 5% 1/10W
R5238 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5241 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5242 1-216-864-11 SHORT CHIP 0
R5244 1-216-864-11 SHORT CHIP 0
R5246 1-216-801-11 METAL CHIP 22 5% 1/10W
DSP
Note: IC5002 and the IC5202 cannot exchange with
single. When IC5002 and the IC5202 are
damaged, exchange the entire mounted board.
