Sony STR-DA5500ES - A-VIDEO Board; A-AUDIO Board

STR-DA5500ES
13
2-7. A-VIDEO BOARD
3
two screws
(BV3
u
8 CU)
2
eight screws
(BVTP3
u
8)
4
screw
(BVTP3
u
8)
6
screw
(BVTP3
u
8)
7
bracket (WB)
8
A-VIDEO board
1
three connectors
(CN6003, CN6008, CN6009)
5
2-8. A-AUDIO BOARD
3
screw
(B3
u
8)
3
seven screws
(BVTP3
u
8)
4
screw
(BVTP3
u
8)
2
four connectors
(CN605, CN606,
CN607, CN608)
1
wire (flat type) (9core)
(CN603)
7
screw
(BVTP3
u
8)
8
bracket (side)
9
A-AUDIO board
5
reinforcement
(main)
6
(US, Canadian)
