STR-DA5500ES
15
2-11. POWER TRANSFORMER (T1), E-VOL/MAIN BOARDS
qh
four screws
(BVTP3
u
8)
qs
lead wire with connector
(CN1001)
qf
two lead wires
qk
screw
(BVTP3
u
8)
qj
three screws
(BV/ring)
qd
Cut the
binding band (taiton).
qd
Cut the
binding band (taiton).
qd
Cut the
binding band (taiton).
6
two screws
(BVTP3
u
8)
w;
screw
(BVTP3
u
8)
w;
two screws
(BVTP3
u
8)
wa
clamp (L35)
qg
two accessory
screws (J1499)
qa
two fuses (T4AL/250V)
(F1403, F1404)
J1499
8
screw
(BVTP3
u
8)
8
screw
(BVTP3
u
8)
ql
reinforcement (MAIN)
q;
E-VOL board
ws
MAIN board
9
bracket
(SS)
9
bracket
(SS)
2
four copper washer
+BVTT assy’s
3
label (TR-ES/L)
4
power
transformer
(T1)
1
two connectors
(CN1404, CN1408)
5
two connectors
(CN1208, CN1209)
7
two connectors
(CN1203, CN1204)
Note: In reassembling, use new binding band (taiton)
to fasten the binding band (taiton) same as before.
