173
STR-DA5500ES
F1405
not supplied
(FILTER board)
1
1
1
9
1
7
1
3
2
2
4
4
5
5
3
8
6
not
supplied
not supplied
D-AUDIO board section
A
B
A
B
C
C
1
10
1
(US, CND)
(US, CND)
(AEP, UK)
SECTION 6
EXPLODED VIEWS
1 4-974-510-11 SCREW (+BV 3X8 CU)
2 3-655-653-01 BAND (TAITON), BINDING
3 1-500-082-11 CLAMP, SLEEVE FERRITE (US, CND)
4 4-227-843-03 SCREW (TP), FLAT HEAD
5 2-580-630-01 SCREW, +BVST 4X8
6 2-668-102-11 CASE
7 1-500-386-11 FILTER, CLAMP (FERRITE CORE)
8 1-543-798-11 FILTER, CLAMP (FERRITE CORE) (AEP, UK)
9 A-1710-798-A DC-DC BOARD, COMPLETE (US, CND)
9 A-1710-896-A DC-DC BOARD, COMPLETE (AEP, UK)
10 A-1710-795-A DCDC2 BOARD, COMPLETE (US, CND)
10 A-1710-893-A DCDC2 BOARD, COMPLETE (AEP, UK)
0 F1405 1-532-506-33 FUSE (T6.3AL/250V)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
Note:
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• The mechanical parts with no reference
number in the exploded views are not sup-
plied.
• Color Indication of Appearance Parts Ex-
ample:
KNOB, BALANCE (WHITE) . . . (RED)
↑ ↑
Parts Color Cabinet’s Color
• Abbreviation
CND : Canadian model
6-1. CASE SECTION
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
Les composants identifi és par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce por-
tant le numéro spécifi é.
The components identifi ed by mark 9 con-
tain confi dential information.
Strictly follow the instructions whenever the
components are repaired and/or replaced.
Les composants identifi és par la marque
9 contiennent des informations confi den-
tielles.
Suivre scrupuleusement les instructions
chaque fois qu’un composant est remplacé
et / ou réparé.
