STR-DA5500ES
10
SECTION 2
DISASSEMBLY
• This set can be disassembled in the order shown below.
2-1. DISASSEMBLY FLOW
Note: Follow the disassembly procedure in the numerical order given.
2-2. CASE
2-2. CASE
(Page 10)
2-4. DSP/D-AUDIO BOARDS
(Page 11)
2-5. CIS/CONTROL BOARDS
(Page 12)
2-6. D-VIDEO/NETWORK BOARDS
(Page 12)
2-10. FRONT PANEL BLOCK
(Page 14)
2-9. HEAT SINK BLOCK
(Page 14)
2-11. POWER TRANSFORMER (T1),
E-VOL/MAIN BOARDS
(Page 15)
2-7. A-VIDEO BOARD
(Page 13)
2-8. A-AUDIO BOARD
(Page 13)
SET
2-3. TUNER (FM/AM),
SPTM BOARD
(Page 11)
3 flat head screw
(TP)
4
4
5 case
2 two flat head screws
(TP)
1
two screws
(
BVST4
u
8
)
1
two screws
(
BVST4
u
8
)
