STR-DA5500ES
137
Pin No. Pin Name I/O Description
H14 DPDVBCK O
Bit clock signal output for digital audio signal output to the lip sync adjust
(US and Canadian models)
Bit clock signal output for digital audio signal output to the fi eld programmable gate array
(AEP and UK models)
J1, J2 AD5, AD4 I/O Two-way data bus with S-RAM and address signal output to the address latch
J4 to J6,
J9 to J11
GND - Ground terminal
J13 VDDINT - Power supply terminal (+1.2V)
J14 DPDVLRCK O
L/R sampling clock signal output for digital audio signal output to the lip sync adjust
(US and Canadian models)
L/R sampling clock signal output for digital audio signal output to the fi eld programmable
gate array (AEP and UK models)
K1 AD3 I/O Two-way data bus with S-RAM and address signal output to the address latch
K2 VDDINT - Power supply terminal (+1.2V)
K4 to K6,
K9 to K11,
K13
GND - Ground terminal
K14 DPSIE I Digital audio signal (for surround back L/R) input from the DSP1
L1, L2 AD2, AD1 I/O Two-way data bus with S-RAM and address signal output to the address latch
L4 to L6,
L9 to L11,
L13
GND - Ground terminal
L14 DPSID I Digital audio signal (for center, subwoofer) input from the DSP1
M1 AD0 I/O Two-way data bus with S-RAM and address signal output to the address latch
M2
WR O Data write enable signal output to the S-RAM
M3, M12 GND - Ground terminal
M13 DPSIB I Digital audio signal (for front L/R) input from the A/D converter, HDMI receiver or DSP1
M14 DPSIC I Digital audio signal (for surround L/R) input from the DSP1
N1 AD15 O Address signal output to the S-RAM and address latch
N2 ALE O Address latch enable signal output to the address latch
N3
RD O Data read enable signal output to the S-RAM
N4 VDDINT - Power supply terminal (+1.2V)
N5 VDDEXT - Power supply terminal (+3.3V)
N6 AD8 O Address signal output to the S-RAM and address latch
N7 VDDINT - Power supply terminal (+1.2V)
N8 DAI_P2 - Not used
N9 VDDEXT - Power supply terminal (+3.3V)
N10 DAI_P4 I Digital audio signal input from the DSP1
N11, N12 VDDINT - Power supply terminal (+1.2V)
N13 GND - Ground terminal
N14 DPSOE O Digital audio signal output terminal Not used
P1 to P6 AD14 to AD9 O Address signal output to the S-RAM and address latch
P7 DAI_P1 O Address signal output to the S-RAM
P8 DAI_P3 - Not used
P9 SF2_DSP2_MAS O Master/slave mode selection signal output terminal
P10 DPSOA O
Digital audio signal (for front L/R) output to the lip sync adjust (US and Canadian models)
Digital audio signal (for front L/R) output to the fi eld programmable gate array
(AEP and UK models)
P11 DPSOB O
Digital audio signal (for surround L/R) output to the lip sync adjust
(US and Canadian models)
Digital audio signal (for surround L/R) output to the fi eld programmable gate array
(AEP and UK models)
P12 DPSOC O
Digital audio signal (for center, subwoofer) output to the lip sync adjust
(US and Canadian models)
Digitalaudio signal (for center, subwoofer) output to the fi eld programmable gate array
(AEP and UK models)
P13 DPSOD O
Digital audio signal (for surround back L/R) output to the lip sync adjust
(US and Canadian models)
Digital audio signal (for surround back L/R) output to the fi eld programmable gate array
(AEP and UK models)
P14 DPSIA I Digital audio signal input from the DSP1
