STR-DA5500ES
158
Pin No. Pin Name I/O Description
167 NO USE - Not used
168 DAC SCL I/O Two-way I2C clock bus terminal Not used
169 VIDEO DAC RESET O Reset signal output to the D/A converter (for video section) “L”: reset
170
2nd VIDEO DAC
RESET
O Reset signal output terminal Not used
171 DAC CLOCK SEL O Clock control signal output to the frequency multiplier for D/A converter (for video section)
172 2nd DAC CLOCK SEL O Clock control signal output terminal Not used
173 NO USE - Not used
174, 175
4052_SEL_A,
4052_SEl_B
O Serial data (for writing) from RS232C connector selection signal output terminal
