STR-DA5500ES
170
Pin No. Pin Name I/O Description
105 VCC - Power supply terminal (+3.3V)
106
SIRIUS POWER
ENABLE
O
Sirius tuner power on/off control signal output to the SIRIUS socket “H” power on
(US and Canadian models only)
107 TUNED I Tuned detection signal input from the tuner (FM/AM) “L”: tuned
108 TUN_LAT O Serial data latch pulse signal output to the tuner (FM/AM)
109 TUN_DATA O Serial data output to the tuner (FM/AM)
110 TUN_CLK O Serial data transfer clock signal output to the tuner (FM/AM)
111 TUN_DO I Serial data input from the tuner (FM/AM)
112 RDS_DATA I RDS serial data input terminal (FM/AM) (AEP and UK models only)
113 NO USE O Not used
114
IR-LEARNING UCOM
RESET
O Reset signal output to the update signal processor “L”: reset
115 IR OUT SWITCH O Relay drive signal (for SIRCS output) output terminal “H”: relay on
116 SIRCS-IN I SIRCS signal input from the remote control receiver
117 DAC_ZERO_DATA I Zero data detection signal input from the D/A converter (for audio section)
118 CEC-DV/M I CEC serial data input from the HDMI IN connector
119 MCK_X1/X2_SEL1 O Master clock signal selection signal output terminal
120 ZONE_SEL I ZONE SELECT switch input terminal
121 MCK_X1/X2_SEL2 O Master clock signal selection signal output terminal
122
PNX SDA (IIC BUS
MONITOR DATA)
I/O Two-way I2C data bus with the parallel bus/I2C bus converter
123 9850 INIT O Reset signal output terminal Not used
124
PNX SCL (IIC BUS
MONITOR CLK)
I/O Two-way I2C clock bus with the parallel bus/I2C bus converter
125 RST_TRG O Reset signal output terminal for system controller “L”: reset
126 XMUART-M/XM O Serial data output to the XM receiver (US and Canadian models only)
127 XMUART-XM/M I Serial data input from the XM receiver (US and Canadian models only)
128 232C-SEL1 O Data (for RS232C connector) selection signal output terminal
129 NO USE O Not used
130 IR-LEARN-UART TX O Serial data output to the update signal processor
131 IR-LEARN-UART RX I Serial data input from the update signal processor
132 VSS - Ground terminal
133 VCC - Power supply terminal (+3.3V)
134 MONI_MUTE O
Composite video monitor out muting on/off control signal output to the video amplifi er
(for composite video signal) “L”: muting on
135 MONI2_MUTE O
Composite video zone 2 out muting on/off control signal output to the video amplifi er
(for composite video signal (for ZONE 2)) “L”: muting on
136 DAC_DO I Serial data input terminal Not used
137 DAC_LAT O Serial data latch pulse signal output terminal Not used
138 DAC_RST O Reset signal output terminal Not used
139 to 142 NO USE O Not used
143 DMPORT2_DETECT I Digital media port adapter connection detection signal input terminal Not used
144 DMUART2-M/DM O Serial data output terminal Not used
145 DMUART2-DM/M I Serial data input terminal Not used
146 COMP_MON_MUTE O
Component video monitor out muting on/off control signal output to the video amplifi er
(for component video signal) “L”: muting on
147 COMP_MON2_MUTE O
Component video zone 2 out muting on/off control signal output to the video amplifi er
(for component video signal (for ZONE 2)) “L”: muting on
148 VSS - Ground terminal
149 VCC - Power supply terminal (+3.3V)
150 SIRIUS_UART_M/SI O Serial data output to the SIRIUS socket (US and Canadian models only)
151 SIRIUS_UART_SI/M I Serial data input from the SIRIUS socket (US and Canadian models only)
152 NO USE O Not used
153 FL_CLR O Clear signal output to the fl uorescent indicator tube
154 FL_DATA O Serial data output to the fl uorescent indicator tube
155 FL_LAT O Serial data latch pulse signal output to the fl uorescent indicator tube
156 FL_CLK O Serial data transfer clock signal output to the fl uorescent indicator tube
157 RDS_CLK I RDS serial data transfer clock signal input terminal (FM/AM) (AEP and UK models only)
