Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DA5500ES
190
D1908 8-719-991-33 DIODE 1SS133T-77
D1909 8-719-991-33 DIODE 1SS133T-77
D1910 8-719-991-33 DIODE 1SS133T-77
< IC >
IC1901 8-759-167-88 IC NJM4565D
< TRANSISTOR >
Q1904 8-729-281-53 TRANSISTOR 2SC1815-GR
Q1905 8-729-042-08 TRANSIST
OR 2SC2389STP-RS
Q1906 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP
Q1907 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP
Q1908 8-729-029-86 TRANSISTOR DTC124ESA
< RESISTOR >
R1521 1-259-440-61 CARBON 3.3K 5% 1/6W
R1522 1-259-428-61 CARBON 1K 5% 1/6W
R1524 1-259-468-61 CARBON 47K 5% 1/6W
R1571 1-259-440-61 CARBON 3.3K 5% 1/6W
R1572 1-259-428-61 CARBON 1K 5% 1/6W
R1574 1-259-468-61 CARBON 47K 5% 1/6W
R1621 1-259-440-61 CARBON 3.3K 5% 1/6W
R1622 1-259-428-61 CARBON 1K 5% 1/6W
R1624 1-259-468-61 CARBON 47K 5% 1/6W
R1721 1-259-440-61 CARBON 3.3K 5% 1/6W
R1722 1-259-428-61 CARBON 1K 5% 1/6W
R1724 1-259-468-61 CARBON 47K 5% 1/6W
R1771 1-259-440-61 CARBON 3.3K 5% 1/6W
R1772 1-259-428-61 CARBON 1K 5% 1/6W
R1774 1-259-468-61 CARBON 47K 5% 1/6W
R1821 1-259-440-61 CARBON 3.3K 5% 1/6W
R1822 1-259-428-61 CARBON 1K 5% 1/6W
R1824 1-259-468-61 CARBON 47K 5% 1/6W
R1871 1-259-440-61 CARBON 3.3K 5% 1/6W
R1872 1-259-428-61 CARBON 1K 5% 1/6W
R1874 1-259-468-61 CARBON 47K 5% 1/6W
R1911 1-247-863-91 CARBON 22K 5% 1/4W
R1912 1-249-429-11 CARBON 10K 5% 1/4W
R1913 1-249-429-11 CARBON 10K 5% 1/4W
R1914 1-247-863-91 CARBON 22K 5% 1/4W
R1915 1-247-863-91 CARBON 22K 5% 1/4W
R1916 1-249-430-11 CARBON 12K 5% 1/4W
R1917 1-247-895-00 CARBON 470K 5% 1/4W
R1918 1-247-871-91 CARBON 47K 5% 1/4W
R1919 1-249-429-11 CARBON 10K 5% 1/4W
R1923 1-247-831-91 CARBON 1K 5% 1/4W
R1929 1-249-429-11 CARBON 10K 5% 1/4W
< VARIABLE RESISTOR >
RV1501 1-238-595-11 RES, ADJ, CARBON 220
RV1551 1-238-595-11 RES, ADJ, CARBON 220
RV1601 1-238-595-11 RES, ADJ, CARBON 220
RV1701 1-238-595-11 RES, ADJ, CARBON 220
RV1751 1-238-595-11 RES, ADJ, CARBON 220
RV1801 1-238-595-11 RES, ADJ, CARBON 220
RV1851 1-238-595-11 RES, ADJ, CARBON 220
************************************************************
CIS BOARD
*********
< CAPACITOR >
C801 1-126-923-91 ELECT 220uF 20% 10V
C802 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C803 1-126-961-11 ELECT 2.2uF 20% 50V
C804 1-126-947-11 ELECT 47uF 20% 35V
C805 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C809 1-162-957-11 CERAMIC CHIP 220PF 5% 50V
C821 1-126-960-11 ELECT 1uF 20% 50V
C831 1-126-960-11 ELECT 1uF 20% 50V
C841 1-126-960-11 ELECT 1uF 20% 50V
C852 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C853 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C854 1-126-947-11 ELECT 47uF 20% 35V
C855 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C856 1-126-947-11 ELECT 47uF 20% 35V
< CONNECTOR >
CN807 1-779-281-11 CONNECTOR, FFC (LIF (NON-ZIF)) 13P
< DIODE >
D801 6-501-817-01 DIODE MA2J1110GLS0
D802 8-719-075-86 LED SID307BRTP19
(REMOTE CONTROL TRANSMITTER)
D803 6-501-817-01 DIODE MA2J1110GLS0
D804 6-501-817-01 DIODE MA2J1110GLS0
D805 6-501-817-01 DIODE MA2J1110GLS0
D808 6-501-817-01 DIODE MA2J1110GLS0
< IC >
IC802 6-700-587-01 IC TC7W53F (TE12R)
IC806 6-600-349-21 IC NJL23H400A
< JACK >
J801
1-563-330-31 JACK (IR REMOTE IN)
J802 1-563-330-31 JACK (IR REMOTE OUT1)
J803 1-563-330-31 JACK (IR REMOTE OUT2)
J821 1-563-330-31 JACK (TRIGGER OUT MAIN)
J831 1-563-330-31 JACK (TRIGGER OUT ZONE2)
J841 1-563-330-31 JACK (TRIGGER OUT ZONE3)
< TRANSISTOR >
Q821 8-729-037-13 TRANSISTOR KTA1271Y
Q822 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q823 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q824 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q825 8-729-216-22 TRANSISTOR 2SA1162-G
Q826 8-729-216-22 TRANSISTOR 2SA1162-G
Q831 8-729-037-13 TRANSISTOR KTA1271Y
Q832 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q841 8-729-037-13 TRANSISTOR KTA1271Y
Q842 8-729-027-43 TRANSISTOR DTC114EKA-T146
< RESISTOR >
R801 1-216-833-11 METAL CHIP 10K 5% 1/10W
R802 1-216-797-11 METAL CHIP 10 5% 1/10W
R803 1-216-845-11 METAL CHIP 100K 5% 1/10W
R804 1-216-833-11 METAL CHIP 10K 5% 1/10W
BIAS CIS
