Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DA5500ES
200
DC-DC DCDC2 DISPLAY
C1413 1-128-950-21 ELECT 1000uF 20% 16V
C1414 1-128-950-21 ELECT 1000uF 20% 16V
C1415 1-128-951-21 ELECT 2200uF 20% 16V
C1416 1-128-950-21 ELECT 1000uF 20% 16V
C1417 1-128-950-21 ELECT 1000uF 20% 16V
C1419 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
C1420 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
C1421 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
C1422 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
C1423 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
C1424 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
C1425 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C1426 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C1427 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C1428 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C1429 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C1430 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
< CONNECTOR >
CN1401 1-691-776-11 PLUG (MICRO CONNECTOR) 14P
* CN1402 1-564-506-11 PLUG, CONNECTOR 3P
* CX1402 1-564-506-11 PLUG, CONNECTOR 3P
CX1451 1-785-101-11 PIN, CONNECTOR (3.96mm PITCH) 3P
< DIODE >
D1401 8-719-072-05 DIODE RBV-602LF-A
D1402 8-719-301-45 DIODE RK14
D1403 8-719-301-45 DIODE RK14
D1404 8-719-312-08 DIODE FMB-G16L
D1405 8-719-301-45 DIODE RK14
D1406 8-719-301-45 DIODE RK14
< FUSE HOLDER >
FH1403 1-533-233-11 FUSE HOLDER
FH1404 1-533-233-11 FUSE HOLDER
< IC >
IC1401 8-759-474-09 IC SI-8050S-LF1101
IC1402 6-711-058-01 IC SI-8008HFE
IC1403 6-71
1-058-01 IC SI-8008HFE
IC1404 8-759-474-09 IC SI-8050S-LF1101
IC1405 6-701-021-01 IC SI-8120JF
< COIL >
L1401 1-456-545-11 COIL, CHOKE 100uH
L1402 1-456-545-11 COIL, CHOKE 100uH
L1403 1-456-545-11 COIL, CHOKE 100uH
L1404 1-456-545-11 COIL, CHOKE 100uH
L1405 1-456-545-11 COIL, CHOKE 100uH
L1406 1-457-508-11 COIL, CHOKE 0.1mH
L1407 1-481-254-11 COIL, CHOKE 0.1mH
L1408 1-481-254-11 COIL, CHOKE 0.1mH
L1409 1-457-508-11 COIL, CHOKE 0.1mH
L1410 1-457-508-11 COIL, CHOKE 0.1mH
< TRANSISTOR >
Q1409 8-729-027-52 TRANSISTOR DTC124EKA-T146
< RESISTOR >
R1401 1-216-041-00 METAL CHIP 470 5% 1/10W
R1402 1-216-025-11 METAL CHIP 100 5% 1/10W
R1403 1-216-033-00 METAL CHIP 220 5% 1/10W
R1404 1-216-041-00 METAL CHIP 470 5% 1/10W
R1405 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R1406 1-216-017-91 METAL CHIP 47 5% 1/10W
R1407 1-216-049-11 METAL CHIP 1K 5% 1/10W
R1408 1-216-017-91 METAL CHIP 47 5% 1/10W
R1409 1-216-025-11 METAL CHIP 100 5% 1/10W
R1410 1-216-049-11 METAL CHIP 1K 5% 1/10W
R1411 1-216-049-11 METAL CHIP 1K 5% 1/10W
R1412 1-216-041-00 METAL CHIP 470 5% 1/10W
R1413 1-216-296-11 SHORT CHIP 0
R1414 1-216-150-91 METAL CHIP 10 5% 1/8W
R1415 1-216-158-00 METAL CHIP 22 5% 1/8W
R1416 1-216-170-00 METAL CHIP 68 5% 1/8W
R1417 1-216-158-00 METAL CHIP 22 5% 1/8W
R1418 1-216-168-00 METAL CHIP 56 5% 1/8W
************************************************************
A-1710-795-A DCDC2 BOARD, COMPLETE (US, CND)
A-1710-893-A DCDC2 BOARD, COMPLETE (AEP, UK)
**********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C1451 1-100-924-21 ELECT 2200uF 20% 35V
C1453 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C1455 1-128-951-21 ELECT 2200uF 20% 16V
C1458 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
< CONNECTOR >
* CN1451 1-564-104-00 PIN, CONNECTOR (3.96mm PITCH) 3P
< DIODE >
D1451 8-719-312-08 DIODE FMB-G16L
< IC >
IC1451 6-711-058-01 IC SI-8008HFE
< COIL >
L1451 1-456-545-11 COIL, CHOKE 100uH
L1453 1-481-254-11 COIL, CHOKE 0.1mH
L1454 1-457-594-11 COIL, LINE FILTER 10uH
< RESISTOR >
R1450 1-216-033-00 METAL CHIP 220 5% 1/10W
R1451 1-216-041-00 METAL CHIP 470 5% 1/10W
R1452 1-216-059-00 METAL CHIP 2.7K 5% 1/10W
R1453 1-216-025-11 METAL CHIP 100 5% 1/10W
R1454 1-216-025-11 METAL CHIP 100 5% 1/10W
************************************************************
A-1710-797-A DISPLAY BOARD, COMPLETE (US, CND)
A-1710-895-A DISPLAY BOARD, COMPLETE (AEP, UK)
***********************
2-389-320-01 CUSHION
< CAPACITOR >
C150 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C151 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
